System And Components
8X-0360 LINES GP-SERVICE BRAKES/N 4XJ1-505; 2TK1-80
Group No: 8X-0360
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P4576 | 1 FLANGE-HALF | 2 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 9B7237 | 2 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8X9937 | 4 HOSE AS | 1 | |
| 5P7466 | 5 CLIP (SLOT) | 1 | |
| 5P7467 | CLIP (TAB) | 1 | |
| 5P8112 | GROMMET | 1 | |
| 6V8801 | 6 NUT (3/8-16-THD) | 1 | |
| 4M2743 | STUD-TAPERLOCK (3/8-16-THD) | 1 | |
| 6V8637 | 7 CONNECTOR | 1 | |
| 6V9853 | ELBOW | 1 | |
| 3D2824 | 8 SEAL-O-RING | 2 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 5P7466 | 9 CLIP (SLOT) | 3 | |
| 5P7467 | CLIP (TAB) | 3 | |
| 5P8112 | GROMMET | 3 | |
| 5P2228 | 10 BOLT (1/2-13X1-IN) | 1 | |
| 8T4223 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 3D0471 | 12 STUD-TAPERLOCK (1/2-13-THD) | 1 | |
| 6V8188 | NUT (1/2-13-THD) | 1 | |
| 3B9818 | SPACER (1.375-IN THK) | 1 | |
| 4D5371 | 13 CLIP | 2 | |
| 7X0345 | 14 BOLT (5/8-11X1.75-IN) | 2 | |
| 8T4122 | 15 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 5T5973 | 16 PLATE | 1 | |
| 8T5429 | 17 ELBOW | 1 | |
| 6V8398 | 18 SEAL-O-RING | 3 | |
| 8W9915 | 19 PLATE | 1 | |
| 9S4191 | 20 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 21 SEAL-O-RING | 3 | |
| 5C6565 | 22 BOLT (1/2-13X1.125-IN) | 6 | |
| 7X0448 | 23 NUT (5/8-11-THD) | 2 | |
| 6V9851 | 24 ELBOW | 1 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 8J5604 | 25 BREATHER AS | 1 | |
| 6P4603 | 26 FILTER GP-OIL | 1 | |
| 8T2502 | 27 BOLT (3/8-16X1.125-IN) | 3 | |
| 6V8724 | 28 ELBOW | 2 | |
| 5T1086 | 29 PLATE | 1 | |
| 8W9925 | 30 PUMP & MOTOR GP-BRAKE RELEASE | 1 | |
| 5S7379 | 31 BOLT (3/8-16X0.875-IN) | 2 | |
| 8T9391 | 32 BOLT (1/2-13X3.75-IN) | 4 | |
| 8T6876 | 33 ELBOW | 1 | |
| 8W6648 | 34 HOSE AS | 1 | |
| 6V8397 | 35 SEAL-O-RING | 4 | |
| 3K0360 | 36 SEAL-O-RING | 1 | |
| 6V9836 | 37 TEE-SWIVEL | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 8W0340 | 38 HOSE AS | 1 | |
| 8X1862 | 39 TUBE AS | 1 | |
| 6V8626 | 40 ELBOW | 2 | |
| 2M9780 | 41 SEAL-O-RING | 6 | |
| 6V9003 | 42 ELBOW | 2 | |
| 8X1861 | 43 TUBE AS | 1 | |
| 6V8642 | 44 CONNECTOR | 2 | |
| 2G5900 | 45 SLACK ADJUSTER GP | 1 | |
| 8W6812 | 46 HOSE AS | 1 | |
| 8J8197 | 47 CLIP | 1 | |
| 8C4436 | 48 BOLT (1/2-13X1.375-IN) | 2 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V9746 | 49 SEAL-O-RING | 2 | |
| 6V0852 | 50 CAP-DUST | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 2 | |
| 3J1907 | 51 SEAL-O-RING | 2 | |
| 4L6459 | 52 BOLT (3/8-16X2.5-IN) | 4 | |
| 6V9007 | 53 ELBOW | 1 | |
| 3D2824 | 54 SEAL-O-RING | 3 | |
| 8X1873 | 55 HOSE AS | 1 | |
| 5M3062 | 56 BOLT (3/8-16X0.75-IN) | 7 | |
| 3K0360 | 57 SEAL-O-RING | 4 | |
| 6V9002 | 58 ELBOW | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 8T4896 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 9M8406 | 60 CLIP (LOOP) | 4 | |
| 9S4183 | 61 PLUG (1-1/16-12-THD) | 1 | |
| 4S4455 | 62 CLIP | 5 | |
| 8X1859 | 63 TUBE AS | 1 | |
| 8X1860 | 64 TUBE AS | 1 | |
| 5T7484 | 65 JUNCTION BLOCK | 2 | |
| 6V8632 | 66 CONNECTOR | 2 | |
| 7J9108 | 67 SEAL-O-RING | 6 | |
| 6V9004 | 68 ELBOW | 1 | |
| 9S4191 | 69 PLUG (9/16-18-THD) | 1 | |
| 6V8636 | 70 CONNECTOR | 1 | |
| 3J1907 | 71 SEAL-O-RING | 6 | |
| 4D5371 | 72 CLIP | 2 | |
| 5T9701 | 73 HOSE AS | 1 | |
| 9W3978 | 74 HOSE AS | 1 | |
| 8X1871 | 75 HOSE AS | 1 | |
| 6V8784 | 76 TEE-FACE SEAL | 2 | |
| 3D2824 | 77 SEAL-O-RING | 3 | |
| 9T4772 | 78 VALVE GP-BRAKE | 1 | |
| 8T2883 | 79 TEE | 1 | |
| 8X6603 | 80 HOSE AS | 1 | |
| 6V8724 | 81 ELBOW | 2 | |
| 6E1851 | 82 TANK GP-BRAKE | 1 | |
| 8T9391 | 83 BOLT (1/2-13X3.75-IN) | 4 | |
| 7X0308 | 84 BOLT (7/16-14X1.375-IN) | 8 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 8 | |
| 1P4578 | 85 FLANGE-HALF | 4 | |
| 4J0522 | SEAL-O-RING | 2 | |
| 8W3405 | 86 CYLINDER GP-AIR/HYDRAULIC | 1 | |
| 9S4185 | 87 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 88 SEAL-O-RING | 3 | |
| 6V8625 | 89 ELBOW | 2 | |
| 6V8723 | 90 ELBOW | 1 | |
| 8X6790 | 91 HOSE AS | 2 | |
| 7X3192 | 92 BOLT (5/8-18X2-IN) | 3 | |
| 8T4122 | WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 6V8398 | 93 SEAL-O-RING | 2 | |
| 6V8629 | 94 ELBOW | 1 | |
| 2M9780 | 95 SEAL-O-RING | 1 | |
| 6V8774 | 96 TEE | 1 | |
| 6V9004 | 97 ELBOW | 1 | |
| 5P5777 | 98 ADAPTER-O-RING | 1 | |
| 7M8485 | 99 SEAL-O-RING | 1 | |
| 8X1872 | 100 HOSE AS | 1 | |
| 6G1444 | 101 ADAPTER | 1 | |
| 1P3707 | SEAL-RECTANGULAR | 1 | |
| 5T9986 | 102 HOSE AS | 1 | |
| 6V8397 | 103 SEAL-O-RING | 10 | |
| 8Y4505 | 104 HOSE AS | 1 | |
| 6V9872 | 105 CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 |
