System And Components
8X-0361 LINES GP-STEERINGS/N 4XJ936-UP; 2TK92-UP
Group No: 8X-0361
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X6423 | 1 BRACKET AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 1 | |
| 5S7379 | 2 BOLT (3/8-16X0.875-IN) | 4 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 8X6425 | 4 GUARD | 1 | |
| 7X0772 | 5 WASHER-HARD (10.2X25.5X2.5-MM THK) | 3 | |
| 6V8635 | 6 CONNECTOR | 1 | |
| 7M8485 | 7 SEAL-O-RING | 2 | |
| 8X1819 | 8 HOSE AS | 1 | |
| 8X1818 | 9 HOSE AS | 1 | |
| 9T3097 | 10 VALVE GP-CHECK | 1 | |
| 1088325 | 11 PLATE AS | 1 | |
| 5M3062 | 12 BOLT (3/8-16X0.75-IN) | 6 | |
| 8X7364 | 13 PLATE | 2 | |
| 8X7553 | 14 PLATE AS | 1 | |
| 1P4579 | 15 FLANGE-HALF | 2 | |
| 3D2824 | 16 SEAL-O-RING | 3 | |
| 9B7237 | 17 BOLT (3/8-16X1.25-IN) | 4 | |
| 6V9746 | 18 SEAL-O-RING | 2 | |
| 5J3399 | 19 PLATE-CONNECTOR | 1 | |
| 4J0525 | SEAL-O-RING | 1 | |
| 5K9090 | 20 SEAL-O-RING | 4 | |
| 8T8920 | 21 BOLT (1/2-13X3.25-IN) | 2 | |
| 8W1599 | 22 TUBE AS | 1 | |
| 4J0527 | 23 SEAL-O-RING | 1 | |
| 8T4835 | 24 BOLT (1/2-13X2-IN) | 2 | |
| 6V9007 | 25 ELBOW | 2 | |
| 2P8421 | 26 ADAPTER-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | 27 ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1P4578 | 28 FLANGE-HALF | 2 | |
| 4J0522 | 29 SEAL-O-RING | 2 | |
| 8T8916 | 30 BOLT (7/16-14X1.5-IN) | 4 | |
| 8T5360 | WASHER (12X22.5X2.5-MM THK) | 4 | |
| 8W4459 | 31 HOSE AS | 1 | |
| 9J9865 | 32 ACCUMULATOR GP-HYDRAULIC | 1 | |
| 8W1525 | 33 HOSE AS | 1 | |
| 5P7470 | 34 CLIP (SLOT) | 1 | |
| 5P7471 | CLIP (TAB) | 1 | |
| 5P8182 | GROMMET (46-MM ID) | 1 | |
| 6F7012 | STUD-TAPERLOCK (3/8-16X1.57-IN) | 1 | |
| 6V8801 | NUT (3/8-16-THD) | 1 | |
| 8W1526 | 35 HOSE AS | 1 | |
| 6E5905 | 36 VALVE GP-FLOW CONTROL | 1 | |
| 7X0293 | BOLT (3/8-16X4.75-IN) | 3 | |
| 8W1524 | 37 HOSE AS | 1 | |
| 4J0524 | 38 SEAL-O-RING | 3 | |
| 5P2566 | 39 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T4223 | 40 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 7K1181 | 41 STRAP-CABLE | 3 | |
| 7G5985 | 42 CLIP (SLOT) | 6 | |
| 7G5984 | 43 CLIP (TAB) | 6 | |
| 7G5986 | 44 GROMMET | 6 | |
| 3D0490 | 45 STUD-TAPERLOCK (1/2-13X1.97-IN) | 4 | |
| 6V8188 | 46 NUT (1/2-13-THD) | 22 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 40 | |
| 8D7296 | 48 JUNCTION BLOCK | 2 | |
| 4J5267 | 49 SEAL-O-RING | 8 | |
| 8X2701 | 50 PLATE | 2 | |
| 8T2502 | 51 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4896 | 52 WASHER-HARD (10.2X18.5X2.5-MM THK) | 42 | |
| 1P4576 | 53 FLANGE-HALF | 12 | |
| 9B7237 | 54 BOLT (3/8-16X1.25-IN) | 24 | |
| 8X1816 | 55 HOSE AS | 1 | |
| 6V9007 | 56 ELBOW | 2 | |
| 3D2824 | 57 SEAL-O-RING | 2 | |
| 3G4667 | 58 VALVE GP-RELIEF (CROSSOVER) | 1 | |
| 8T9101 | 59 BOLT (3/8-16X2.75-IN) | 6 | |
| 8X1817 | 60 HOSE AS | 2 | |
| 2D8426 | 61 STUD-TAPERLOCK (1/2-13X3.19-IN) | 8 | |
| 7G3834 | 62 CLIP (SLOT) | 4 | |
| 7G3833 | CLIP (TAB) | 4 | |
| 7G3832 | GROMMET | 4 | |
| 9D7269 | 63 HOSE AS | 1 | |
| 5P7466 | 64 CLIP (SLOT) | 2 | |
| 5P7467 | CLIP (TAB) | 2 | |
| 5P8112 | GROMMET | 2 | |
| 6V9850 | 65 ELBOW | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 8X1815 | 66 HOSE AS | 1 | |
| 1163271 | 67 HOSE AS | 1 | |
| 1P4582 | 68 FLANGE-HALF | 2 | |
| 4J0527 | 69 SEAL-O-RING | 2 | |
| 5P2566 | 70 BOLT (1/2-13X1.5-IN) | 6 | |
| 8P9859 | 71 ELBOW | 1 | |
| 7X0331 | 72 BOLT (1/2-13X4.25-IN) | 2 | |
| 7X0325 | BOLT (1/2-13X2.5-IN) | 2 | |
| 4L6454 | 73 BOLT (3/8-16X1-IN) | 4 | |
| 6G1549 | 74 PLATE AS | 1 | |
| 5M3062 | 75 BOLT (3/8-16X0.75-IN) | 4 | |
| 6G1548 | 76 CLIP | 2 | |
| 6V9746 | 77 SEAL-O-RING | 4 | |
| 9T6865 | 78 PLUG-ADAPTER | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 8C3451 | CAP-DUST (HYDRAULIC OIL) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 3J7354 | 79 SEAL-O-RING | 2 |
