4W-7005 CYLINDER HEAD GPS/N 48W34695-99999

Group No: 4W-7005
Part NumberPart NameQty
7W80711 BRACKET-FUEL PUMP1
3B19152 BOLT (3/8-16X1.375-IN)1
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)2
0S16084 BOLT (3/8-16X3.75-IN)1
1A51835 BOLT (3/8-16X4.75-IN)1
5B26386 BOLT (3/8-16X5.25-IN)1
6N67317 SUPPORT-HOUSING (LH)1
7E73088 GASKET-CYLINDER HEAD2
2H37509 BOLT (3/4-16X7.5-IN)28
5H150410 WASHER-HARD (20X33.5X5-MM THK)28
7W222411 CYLINDER HEAD GP2
0L135212 BOLT (3/8-16X3.25-IN)7
8T676413 PLUG-PIPE1
0L135214 BOLT (3/8-16X3.25-IN)4
4N093215 PLUG-CUP2
5P006316 PLUG-CUP4
100692017 ADAPTER-NOZZLE8
3E677218 SEAL32
106179219 STUD-TAPERLOCK (3/8-16X4-IN)16
7X773120 PLUG-PIPE2
8T676221 PLUG-PIPE4
4N725322 GASKET-CHAMBER8
8T676423 PLUG-PIPE1
6N673224 SUPPORT-HOUSING (RH)1
5B263825 BOLT (3/8-16X5.25-IN)1
1A518326 BOLT (3/8-16X4.75-IN)1
5M289427 WASHER-HARD (10.2X18.5X2.5-MM THK)3
0S159128 BOLT (3/8-16X1.5-IN)1
8S919129 BOLT (3/8-16X4-IN)2
1W520730 BRACKET-FUEL PUMP1
8M524931 SEAL-O-RING8
8T676232 PLUG-PIPE (LH)2
