System And Components
6G-9415 CONTROL GP-GOVERNORS/N 1FB532-659
Group No: 6G-9415
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3D7587 | 1 ELBOW (EXTERNAL PIPE) | 1 | |
| 4K8302 | 2 CLIP (LOOP) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 4 | |
| 4D7969 | 4 HOSE AS | 1 | |
| 6K8076 | 5 CONNECTOR (INVERTED FLARE I.D.) | 1 | |
| 4H6147 | 6 CONNECTOR (DOUBLE FITTING) | 2 | |
| 7N3718 | 7 CLIP | 1 | |
| 5T4909 | 8 TUBE AS | 1 | |
| 5T3987 | 9 TUBE AS | 1 | |
| 5K9246 | 10 CONNECTOR | 2 | |
| 9M8662 | 11 COUPLING | 2 | |
| 4S7560 | 12 HOSE AS | 1 | |
| 5K9246 | 13 CONNECTOR | 2 | |
| 6G4700 | 14 VALVE GP-AIR CONTROL | 1 | |
| 5T1577 | 15 TUBE AS | 1 | |
| 5T1576 | 16 TUBE AS | 1 | |
| 5K9248 | 17 CONNECTOR | 1 | |
| 2M1908 | 18 FITTING-BULKHEAD | 1 | |
| 5M6214 | 19 PLUG (1/8-27 PTF) | 1 | |
| 2G3787 | 20 BUTTON | 1 | |
| 5T1202 | SHAFT | 1 | |
| 2D6403 | 21 PIN-SPRING | 2 | |
| 6G8920 | 22 VALVE GP-AIR CONTROL | 1 | |
| 9S7698 | 23 ELBOW-FLARED | 2 | |
| 5T3970 | 24 TUBE AS | 1 | |
| 1P3458 | CONNECTOR | 1 | |
| 5T3972 | 25 TUBE AS | 1 | |
| 5T3971 | 26 TUBE AS | 1 | |
| 5K9235 | 27 ELBOW-FLARED | 1 | |
| 8T8908 | 28 BOLT (1/4-20X1-IN) | 3 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 1B0676 | 29 PIN | 2 | |
| 7V0446 | CLIP | 2 | |
| 1A9252 | 30 END-ADJUSTMENT ROD | 2 | |
| 5B9079 | 31 NUT-JAM (3/8-24-THD) | 2 | |
| 5D1185 | 32 ROD-CONTROL | 1 | |
| 9S8006 | 33 PLUG (7/8-14-THD) | 4 | |
| 5T8919 | 34 BEARING | 4 | |
| 1B4669 | 35 COLLAR-SET | 2 | |
| 4B3573 | SETSCREW-SQUARE HEAD (3/8-16X0.625-IN) | 2 | |
| 1B2578 | 36 NUT (3/8-16-THD) | 2 | |
| 0314155 | 37 LOCKNUT (5/16-18-THD) | 6 | |
| 8T9043 | 38 BOLT (5/16-18X0.875-IN) | 6 | |
| 8T4224 | 39 WASHER-HARD (8.8X16X2-MM THK) | 14 | |
| 8W0389 | 40 SHAFT | 1 | |
| 6D4397 | 41 ROTOCHAMBER GP | 1 | |
| 4H6141 | 42 CONNECTOR | 2 | |
| 6V8801 | 43 NUT (3/8-16-THD) | 7 | |
| 4L9337 | 44 BOLT (3/8-16X1.5-IN) | 4 | |
| 4D8919 | 45 LEVER | 1 | |
| 1B8704 | 46 KEY-WOODRUFF | 4 | |
| 6V2383 | 47 CLIP | 1 | |
| 5P8167 | BOLT (3/8-16X0.625-IN) | 1 | |
| 5M3062 | 48 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 7J8581 | 50 CLIP | 1 | |
| 5V2823 | GROMMET | 2 | |
| 4J2684 | 51 LEVER | 2 | |
| 5J5315 | 52 ROD END | 1 | |
| 2F8616 | NUT-SELF LOCKING (3/8-24-THD) | 1 | |
| 5B9079 | 53 NUT-JAM (3/8-24-THD) | 4 | |
| 2R1528 | 54 ROD | 1 | |
| 4D4064 | 55 ROD END (3/8-24-THD) | 3 | |
| 5S7382 | 56 BOLT (3/8-16X1.375-IN) | 3 | |
| 4K5973 | 57 LEVER | 1 | |
| 5T8836 | 58 PLATE AS | 1 | |
| 5T8843 | 59 SHAFT | 1 | |
| 6V8189 | 60 NUT (5/16-18-THD) | 1 | |
| 8C3121 | BOLT (5/16-18X1.5-IN) | 1 | |
| 1102908 | 61 LEVER-GOVERNOR | 1 | |
| 6D0475 | 62 LINK AS-SPRING | 1 | |
| 3S6956 | 63 ROD | 1 | |
| 4L6454 | 64 BOLT (3/8-16X1-IN) | 2 | |
| 5K0906 | 65 BOLT (5/16-18X0.625-IN) | 2 | |
| 5T8842 | 66 BLOCK | 1 | |
| 8C3448 | 67 BOLT (3/8-16X2.25-IN) | 2 | |
| 7X0772 | 68 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 6G4438 | 69 PEDAL | 2 | |
| 5S7382 | BOLT (3/8-16X1.375-IN) | 2 | |
| 7X0860 | 70 BOLT (3/8-16X1.5-IN) | 2 | |
| 1B2578 | NUT (3/8-16-THD) | 2 | |
| 8J4916 | 71 BOSS (3/8-16-THD) | 1 | |
| 5S7379 | 72 BOLT (3/8-16X0.875-IN) | 9 | |
| 8T4896 | 73 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 4J2701 | 74 ROD END | 1 | |
| 2D7325 | 75 TEE-PIPE | 1 | |
| 4H6141 | 76 CONNECTOR | 2 | |
| 5T4017 | 77 TUBE AS | 1 | |
| 9S7698 | 78 ELBOW-FLARED | 1 | |
| 3B7721 | BUSHING-REDUCER | 1 | |
| 9D0338 | 79 VALVE GP-CHECK | 1 | |
| 3J5390 | 80 PLUG (3/8-18-THD) | 1 | |
| 5K9237 | 81 ELBOW-FLARED | 1 | |
| 4L9337 | 82 BOLT (3/8-16X1.5-IN) | 1 | |
| 6V8801 | 83 NUT (3/8-16-THD) | 3 | |
| 5D1849 | 84 LEVER | 1 | |
| 1B8704 | KEY-WOODRUFF | 1 | |
| 1B0676 | 85 PIN | 1 | |
| 7V0446 | CLIP | 1 | |
| 4D4064 | 86 ROD END (3/8-24-THD) | 1 | |
| 5B9079 | NUT-JAM (3/8-24-THD) | 1 | |
| 4K4726 | 87 ROD END | 1 | |
| 5S7382 | 88 BOLT (3/8-16X1.375-IN) | 2 | |
| 6G4448 | 89 LEVER | 2 | |
| 6V5782 | BOLT (5/16-18X1.125-IN) | 2 | |
| 1B8706 | 90 KEY-WOODRUFF | 4 | |
| 6G4661 | 91 HOUSING AS | 2 | |
| 5P7661 | BEARING AS-NEEDLE | 1 | |
| 6D3787 | BEARING-ROLLER | 1 | |
| 6G8909 | 92 SHAFT | 2 | |
| 7S9203 | WASHER | 2 | |
| 3K9042 | RING-RETAINING | 2 |
