System And Components
5T-1283 LINES GP-FUELS/N 2PD1011-99999
Group No: 5T-1283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W3100 | 1 HOSE AS | 1 | |
| 8W3101 | 2 HOSE AS | 1 | |
| 5K5338 | 3 CLIP (LOOP) | 4 | |
| 8W3107 | 4 HOSE AS | 1 | |
| 3S8664 | 5 CLIP | 3 | |
| 1050251 | 6 HOSE AS | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8397 | 7 SEAL-O-RING | 5 | |
| 7W9156 | 8 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8W3106 | 9 HOSE AS | 1 | |
| 3S2093 | 10 STRAP-CABLE | 3 | |
| 5P8167 | 11 BOLT (3/8-16X0.625-IN) | 3 | |
| 8T4896 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8J8197 | 13 CLIP | 1 | |
| 8W4302 | 14 HOSE AS | 1 | |
| 6V9168 | 15 NUT (11/16-16-THD) | 1 | |
| 6V8994 | 16 UNION (STRAIGHT) | 1 | |
| 5T2273 | 17 TUBE AS | 1 | |
| 5T2272 | 18 TUBE AS | 1 | |
| 6V8996 | 19 UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 6V9170 | 20 NUT-BULKHEAD (1-14-THD) | 1 | |
| 2H3924 | LOCKWASHER | 1 | |
| 8T8908 | 21 BOLT (1/4-20X1-IN) | 1 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V8625 | 22 ELBOW | 2 | |
| 6V8398 | 23 SEAL-O-RING | 11 | |
| 3K0360 | 24 SEAL-O-RING | 3 | |
| 8T0081 | 25 VALVE-BALL | 1 | |
| 8T2502 | 26 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4896 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8W0552 | 28 TUBE AS | 1 | |
| 6V8721 | 29 ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8981 | 30 ELBOW | 2 | |
| 6V9169 | 31 NUT (13/16-16-THD) | 4 | |
| 6V9353 | 32 UNION | 1 | |
| 7J9108 | 33 SEAL-O-RING | 5 | |
| 8W0553 | 34 TUBE AS | 1 | |
| 5P8874 | 35 ADAPTER | 1 | |
| 3J1907 | 36 SEAL-O-RING | 2 | |
| 9S4182 | 37 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V9873 | 38 CONNECTOR | 1 | |
| 8W0554 | 39 TUBE AS | 1 | |
| 8W0551 | 40 TUBE AS | 1 | |
| 6V8995 | 41 UNION (STRAIGHT) | 1 | |
| 6V9170 | 42 NUT-BULKHEAD (1-14-THD) | 2 | |
| 6V8982 | 43 ELBOW | 1 | |
| 2H3924 | 44 LOCKWASHER | 2 | |
| 6V8996 | 45 UNION | 1 | |
| 6V8994 | 46 UNION (STRAIGHT) | 1 | |
| 6V8397 | 47 SEAL-O-RING | 3 | |
| 6V9168 | 48 NUT (11/16-16-THD) | 2 | |
| 8W3102 | 49 HOSE AS | 1 | |
| 8W3103 | 50 HOSE AS | 1 |
