System And Components
5T-1279 FENDER GPS/N 2PD1011-99999
Group No: 5T-1279
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8D6086 | 1 FENDER AS (RH) | 1 | |
| 4L6454 | 2 BOLT (3/8-16X1-IN) | 5 | |
| 8T4897 | 3 WASHER (10.2X35X6-MM THK) | 33 | |
| 5T2040 | 4 FENDER AS (LH) | 1 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 5M6708 | 6 WASHER (0.609X1.25X0.219-IN THK) | 5 | |
| 8D6085 | 7 SPACER | 5 | |
| 8D6088 | 8 SHIELD AS | 1 | |
| 8X9693 | 9 BRACKET AS | 1 | |
| 2G8690 | 10 CLIP AS | 2 | |
| 5T2042 | 11 SHIELD AS | 1 | |
| 9B7237 | 12 BOLT (3/8-16X1.25-IN) | 27 | |
| 6V8801 | 13 NUT (3/8-16-THD) | 18 | |
| 2J3505 | 14 NUT-FULL (7/8-9-THD) | 6 | |
| 5P8249 | 15 WASHER-HARD (24X41.5X4-MM THK) | 6 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 10 | |
| 8X9694 | 17 BRACKET AS | 1 | |
| 0318590 | 18 SPACER (0.6325X0.875X0.25-IN THK) | 4 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 4 |
