6G-9605 HITCH GP-CUSHIONS/N 2PD1011-99999

Group No: 6G-9605

Part Number	Part Name	Qty
1071216	1 FRAME AS	1
8J7596	2 BUSHING	2
8W4523	BUSHING	2
9J9427	3 BUSHING	4
9J8318	BUSHING (1.52MM OS)	4
1021444	4 BEARING	2
8W4527	BEARING (1.52-MM OS)	2
3G7894	5 LINK AS	2
7J8458	6 BUSHING	4
5T9627	7 RETAINER AS	1
8W4496	8 RETAINER	1
3G7853	9 RETAINER	7
2J5637	10 PIN	1
8J0632	11 PIN	4
8C4436	12 BOLT (1/2-13X1.375-IN)	56
7J3663	13 WASHER-THRUST	8
8W9517	14 SPACER (71.5X120X3-MM THK)	1
8T4223	15 WASHER-HARD (13.5X25.5X3-MM THK)	68
8T4994	16 WASHER-HARD (20X36.5X3.5-MM THK)	6
4H2686	17 RING	2
6V8849	18 BOLT-12 POINT HEAD (3/4-10X3-IN)	4
6G5155	19 BEARING-THRUST	2
1021441	20 RETAINER	1
3H5240	21 NUT (2-3/4-12-THD)	1
8W9515	22 PIN AS	1
8J7727	23 PIN	1
3B4627	24 PIN-COTTER	1
4J5692	25 WASHER-THRUST (4X6.81X0.249-IN THK)	1
4J5689	26 WASHER (4X7.75X0.308-IN THK)(STEEL-PLAIN)	1
4J5691	WASHER (101.6X196.85X6.32-MM THK)(BRONZE-DRILLED)	1
4J5690	WASHER (5.38X7.75X0.308-IN THK)(STEEL-DRILLED)	1
8T9399	27 BOLT (3/4-10X2.25-IN)	2
1021440	28 RETAINER	1
1021442	29 RETAINER	1
1021443	30 RETAINER	1
5T8528	31 PIN AS	4
9J2323	32 WASHER (2.5X5X0.26-IN THK)	2
8W4791	33 LINK-REAR STEERING	2
9J2171	34 SPACER (69.8X73X68.6-MM)	2
5T3323	35 PIN AS	2
5T8525	36 PLATE	4
3G9316	37 PLATE	1
8T8917	38 BOLT (1/2-13X1.25-IN)	8
5T4649	39 SPACER-SPECIAL	4
8T9393	40 BOLT (5/8-11X1.5-IN)	4
8T4122	WASHER-HARD (17X32X3.5-MM THK)	4
8T8920	41 BOLT (1/2-13X3.25-IN)	4
5T0847	42 BRACKET	1
5T4648	43 STUD-TAPERLOCK (3/4-10-THD)	2
5T8526	44 PIN AS	2
1K6870	45 LOCKNUT (3/4-10-THD)	2
1071220	46 BRACKET AS	1
4J5694	47 BUSHING	1
8W4526	BEARING (1.52-MM OS)	1
5J6611	48 BUSHING	2
8W4522	BEARING (1.52-MM OS)(1.52MM OVERSIZE)	2
9J9427	49 BUSHING	4
9J8318	BUSHING (1.52MM OS)	4
5T1035	50 LINK AS-FRONT STEERING	2
5T0846	LINK-FRONT STEERING	1
9J1676	51 BUSHING	4
8W9267	SHIM (0.5-MM THK)(.5MM THK)
