System And Components
8X-1612 HOOD GP-TRACTORS/N 2PD1011-99999
Group No: 8X-1612
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X1775 | 1 HOOD AS | 1 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 3 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 5C3162 | BLOCK | 1 | |
| 4L6454 | 2 BOLT (3/8-16X1-IN) | 10 | |
| 8T4896 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 8M4069 | 4 WASHER (10.3X38.1X5-MM THK) | 3 | |
| 8X1663 | 5 PAD | 1 | |
| 9B7237 | 6 BOLT (3/8-16X1.25-IN) | 6 | |
| 7X0503 | WASHER-HARD (10.2X28.5X5-MM THK) | 6 | |
| 8W5239 | 7 BAFFLE | 1 | |
| 6N8744 | 8 MOUNT | 6 | |
| 8X1782 | 9 HOOD AS | 1 | |
| 5T8062 | 10 ROD AS | 1 | |
| 0T0431 | WASHER (10.3X19X2.5-MM THK)(2.5MM THK) | 1 | |
| 2G8768 | WASHER (10.5X53.8X3-MM THK) | 1 | |
| 2G8768 | 11 WASHER (10.5X53.8X3-MM THK) | 1 | |
| 3B4615 | 12 PIN-COTTER | 2 | |
| 4D6082 | 13 BOLT (1/2-13X1.5-IN) | 3 | |
| 0T0883 | 14 WASHER (0.531X1X0.065-IN THK) | 3 | |
| 3B4610 | PIN-COTTER | 3 | |
| 8W8052 | 15 PLATE AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 3 |
