5T-0650 CONTROL GP-STEERINGS/N 2PD1011-99999

Group No: 5T-0650
Part NumberPart NameQty
6G83641 PLATE AS1
5T47952 COVER1
4L64543 BOLT (3/8-16X1-IN)8
8T4896WASHER-HARD (10.2X18.5X2.5-MM THK)8
6G77844 PLATE1
5Y09745 SCREW-BUTTON HEAD (1/4-20X0.5-IN)5
5P4115WASHER-HARD (7.2X19X2-MM THK)5
5P24246 BOLT (1/2-13X2.25-IN)2
8T42237 WASHER-HARD (13.5X25.5X3-MM THK)6
5T07008 UNIVERSAL JOINT GP-STEERING1
2K48219 LOCKNUT (5/8-18-THD)1
8T4122WASHER-HARD (17X32X3.5-MM THK)1
8W073410 STEERING WHEEL1
5T926011 COVER1
5T781512 SHAFT-STEERING1
6G782813 SUPPORT1
6G7818PLUNGER1
5T6153SHIM (.20MM THK)14
5T444714 GRIP1
5T045415 HANDLE AS1
1D5874SPACER (0.766X1.25X1.125-IN THK)1
6G758716 SUPPORT1
9B723717 BOLT (3/8-16X1.25-IN)1
4N0205SPACER (0.42X0.75X0.6-IN THK)1
6G835118 LEVER1
5H262319 SPRING1
1J438420 PIN-CLEVIS1
3B4617PIN-COTTER1
7X032621 BOLT (1/2-13X3-IN)4
6G747322 SUPPORT1
8W000523 BEARING1
4L8017RING-RETAINING1
8W0006SEAL1
5T045524 COLUMN AS1
5B198325 BOSS (3/8-16-THD)2
4F593226 STOP1
3K535927 LUG1
5T044828 CABLE AS1
5T044629 PULLEY1
8H432030 BALL BEARING2
6G000931 BRACKET2
031021532 BOLT-LOCKING (1/4-20X0.625-IN)3
8T4205WASHER-HARD (7.2X14.5X2-MM THK)3
2B588633 BUSHING1
3B530134 PIN-COTTER1
2K797935 BUSHING2
6F925436 WASHER-THRUST2
4L933737 BOLT (3/8-16X1.5-IN)1
8T489638 WASHER-HARD (10.2X18.5X2.5-MM THK)8
6G835239 SPRING1
3P902940 KEY1
6G827841 SEAL AS1
9D386842 SCREW (BUTTON HEAD)4
6G780243 PLATE1
8T250244 BOLT (3/8-16X1.125-IN)7
6K816245 RING-RETAINING1
5H648046 RING-RETAINING1
6V381247 BEARING AS-BALL1
5M621348 PLUG-PIPE (1/4-18-THD)2
