System And Components
7E-5683 LINES GP-TURBOCHARGER OILS/N 6NC1-99999; 08Z66000-99999
Group No: 7E-5683
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E9302 | 1 TUBE AS-OIL | 1 | |
| 7E9303 | 2 TUBE AS-OIL DRAIN | 1 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 6N6033 | 4 CLIP | 2 | |
| 1B2790 | 5 BOLT (5/16-18X1.375-IN) | 1 | |
| 8H9788 | 6 GASKET | 1 | |
| 4B3388 | 7 BOLT (5/16-18X1.125-IN) | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 3 | |
| 1184728 | 11 ELBOW | 1 | |
| 3K0360 | 12 SEAL-O-RING | 2 | |
| 9N5328 | 13 ADAPTER | 1 | |
| 4M6480 | 14 GASKET | 1 | |
| 0L1143 | 15 BOLT (3/8-16X2.5-IN) | 1 | |
| 9S4185 | 16 PLUG (3/4-16-THD) | 1 | |
| 8T6765 | 17 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4W1512 | 18 SUPPORT AS-PUMP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8M5248 | 19 SEAL-O-RING | 2 | |
| 9S8002 | 20 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 21 SEAL-O-RING | 1 | |
| 9M4849 | 22 SEAL-O-RING | 1 | |
| 8M5253 | 23 SEAL-O-RING | 1 | |
| 1886126 | 24 GASKET | 1 | |
| 0S1617 | 25 BOLT (5/16-18X0.75-IN) | 1 | |
| 5S0003 | 26 NUT (5/16-18-THD) | 1 | |
| 0S1608 | 27 BOLT (3/8-16X3.75-IN) | 1 |
