4W-7005 CYLINDER HEAD GPS/N 48W34100-99999

Group No: 4W-7005
Part NumberPart NameQty
7W80711 BRACKET-FUEL PUMP1
3B19152 BOLT (3/8-16X1.375-IN)1
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)2
0S16084 BOLT (3/8-16X3.75-IN)1
1A51835 BOLT (3/8-16X4.75-IN)1
5B26386 BOLT (3/8-16X5.25-IN)1
6N67317 SUPPORT-HOUSING (LH)1
28356668 GASKET-CYLINDER HEAD2
2H37509 BOLT (3/4-16X7.5-IN)28
5H150410 WASHER-HARD (20X33.5X5-MM THK)28
7W222411 CYLINDER HEAD GP2
0L135212 BOLT (3/8-16X3.25-IN)7
0L1352BOLT (3/8-16X3.25-IN)4
4N093213 PLUG-CUP (57.53-MM OD)2
5P006314 PLUG-CUP4
100692015 ADAPTER-NOZZLE8
359143916 SEAL AS-WATER32
4S613717 STUD-TAPERLOCK (3/8-16X3.1-IN)16
7X773118 PLUG-PIPE (3/4-14-THD)2
8T676219 PLUG-PIPE (1/2-14-THD)5
4N725320 GASKET-CHAMBER8
8T676421 PLUG-PIPE (1/8-27-THD)1
6N673222 SUPPORT-HOUSING (RH)1
5B263823 BOLT (3/8-16X5.25-IN)1
1A518324 BOLT (3/8-16X4.75-IN)1
5M289425 WASHER-HARD (10.2X18.5X2.5-MM THK)3
0S159126 BOLT (3/8-16X1.5-IN)1
8S919127 BOLT (3/8-16X4-IN)2
1W520728 BRACKET-FUEL PUMP1
8M524929 SEAL-O-RING8
8T676430 PLUG-PIPE (1/8-27-THD)1
8T676231 PLUG-PIPE (1/2-14-THD)(RH)1
