System And Components
6G-9930 TANK GP-HYDRAULICS/N 3ND523-99999
Group No: 6G-9930
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G7233 | 1 FILTER GP-OIL | 1 | |
| 6G1249 | GASKET | 1 | |
| 6G9974 | 2 TUBE AS | 1 | |
| 7F8268 | SEAL-O-RING | 1 | |
| 0310219 | 3 BOLT-LOCKING (3/8-16X1.75-IN) | 8 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8W2966 | 5 COVER | 1 | |
| 4J0525 | SEAL-O-RING | 1 | |
| 6K5718 | BOLT-LOCKING | 2 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 36 | |
| 2K4973 | 7 LOCKNUT (3/8-16-THD) | 37 | |
| 9S1366 | 8 BOLT (1/2-13X2.5-IN) | 2 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5T4624 | 10 MOUNTING | 1 | |
| 0L2070 | 11 BOLT (3/8-16X2.25-IN) | 1 | |
| 6N8863 | WASHER (10.2X32X2.5-MM THK) | 3 | |
| 6G9765 | 12 TUBE AS | 1 | |
| 2H6338 | 13 SEAL-O-RING | 1 | |
| 5K7143 | 14 BOLT-SELF-LOCKING (1/2-13X1.5-IN) | 2 | |
| 2G9354 | 15 COVER AS | 1 | |
| 5D4218 | BLOCK | 1 | |
| 2G9356 | GASKET | 1 | |
| 6E1677 | 16 TANK AS-HYDRAULIC | 1 | |
| 2G9034 | 17 COVER | 1 | |
| 1J8595 | GASKET | 1 | |
| 2K4973 | 18 LOCKNUT (3/8-16-THD) | 40 | |
| 5T4617 | 19 COVER AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 5D0353 | 20 BOLT-LOCKING (3/8-16X1-IN) | 4 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 6G9987 | 22 ELBOW | 1 | |
| 4D6082 | 23 BOLT (1/2-13X1.5-IN) | 1 | |
| 0T0883 | WASHER (0.531X1X0.065-IN THK) | 1 | |
| 3B4610 | PIN-COTTER | 1 | |
| 5H8985 | 24 PIN-SPRING | 1 | |
| 0307335 | 25 BOLT-LOCKING (5/8-11X1.5-IN) | 4 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 5T0096 | 26 SCREEN AS | 1 | |
| 3B0551 | 27 PLUG-PIPE | 1 | |
| 5K7143 | 28 BOLT-SELF-LOCKING (1/2-13X1.5-IN) | 6 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 9S9993 | 29 ADAPTER | 1 | |
| 9H6687 | PIN-SPRING | 1 | |
| 5M2669 | 30 PLUG-OIL DRAIN | 1 | |
| 5T0093 | 31 HOSE | 1 | |
| 8L8137 | 32 CLIP | 1 | |
| 5K9107 | BOLT-LOCKING (3/8-16X0.75-IN) | 1 | |
| 6G9988 | 33 ELBOW | 1 | |
| 2H6338 | 34 SEAL-O-RING | 2 | |
| 5P1717 | 35 CLAMP-HOSE | 4 | |
| 0S1594 | 36 BOLT (3/8-16X1-IN) | 40 | |
| 2M9189 | 37 GASKET | 1 | |
| 5D1902 | 38 COVER-HYDRAULIC CAP | 1 | |
| 7B2805 | 39 RING-LOCK | 1 | |
| 5D1901 | 40 WASHER (106.5X126.5X2.5-MM THK) | 1 | |
| 4J3816 | 41 PLATE | 1 | |
| 4J3815 | GASKET | 1 | |
| 1L5072 | 42 DOWEL | 1 | |
| 9M7394 | 43 LEVER | 1 | |
| 8T2275 | 44 BALL | 1 | |
| 4J3754 | 45 CAP-FILLER | 1 | |
| 1M8649 | 46 RING-RETAINING | 1 | |
| 0352017 | 47 SCREW-BUTTON HEAD (3/8-16X1-IN) | 4 | |
| 3D6678 | 48 STRAINER (METAL) | 1 | |
| 6J1081 | 49 GLASS-SIGHT | 1 | |
| 6J1080 | 50 GROMMET | 1 | |
| 6J1126 | 51 PLATE-INDICATOR | 1 | |
| 9J8243 | 52 RETAINER | 1 | |
| 5H6005 | 53 SEAL-O-RING | 4 |
