Assembly
100%

8N-9267 CYLINDER BLOCK GPS/N 11N1-8495; 70V34826-99999

Group No: 8N-9267
Part NumberPart NameQty
7W49901 JET AS-PISTON COOLING6
8T67572 PLUG-PIPE3
7M74103 PLUG-PIPE1
2W60004 LINER-CYLINDER BLOCK6
8T67635 PLUG-PIPE (1/4-18-THD)3
1S95406 DOWEL2
3S54967 SEAL-O-RING2
7W64928 PLUG-PIPE (1/2-14-THD)1
03075719 BOLT (3/8-16X1-IN)4
4W858510 COVER1
7W608111 GASKET1
2M647112 PLUG-CUP1
4N068313 DOWEL4
4N165014 DOWEL2
6I298115 PLATE-BLOCK1
6I402416 GASKET-PLATE1
8S909417 PLUG-ORIFICE1
9S419018 PLUG-O-RING (7/8-14-THD)1
2M978019 SEAL-O-RING1
8T676720 PLUG-PIPE (3/8-18-THD)6
7E647921 BOLT-SPECIAL (OIL JET)6
4N068522 BUSHING (1-IN WIDE)6
4N665823 BUSHING (1.3-IN WIDE)1
8T676424 PLUG-PIPE (1/8-27-THD)1
9S800925 PLUG-O-RING1
4K138826 SEAL-O-RING1
110222027 SEAL-LINER18
3P132328 BOLT-BEARING CAP (7/8-14X7.75-IN)14
9H103129 WASHER-HARD (24X41.5X6-MM THK)14
4N585730 CAP-CRANKSHAFT BEARING7
9L585431 BAND-FILLER (130.2-MM ID)6
4W458832 SLEEVE-LIFTER BORE
4W6061SLEEVE
9S419033 PLUG-O-RING (7/8-14-THD)1
2M978034 SEAL-O-RING1
100739935 PLUG1
3E674736 SEAL-O-RING1
5N0093INSERT-LINER SEAT (2.71-MM THK)
6I4365INSERT-LINER SEAT (2.66-MM THK)
6I4366INSERT-LINER SEAT (2.76-MM THK)
2W3815INSERT-LINER SEAT (1.605-MM THK)
6I4363INSERT-LINER SEAT (1.555-MM THK)
6I4364INSERT-LINER SEAT (1.655-MM THK)
9Y3368INSERT-LINER SEAT (0.822-MM THK)
6I4361INSERT-LINER SEAT (0.772-MM THK)
6I4362INSERT-LINER SEAT (0.872-MM THK)
