Assembly
100%

137-6336 AFTERCOOLER GP-WATERS/N 11N1-15937; 70V34826-99999

Group No: 137-6336
Part NumberPart NameQty
1B95751 BOLT (5/16-18X1.56-IN)11
9M19742 WASHER-HARD (8.8X16X2-MM THK)26
8N80993 COVER1
8T67654 PLUG-PIPE (1/4-18-THD)1
8T67645 PLUG-PIPE (1/8-27-THD)1
5M28946 WASHER-HARD (10.2X18.5X2.5-MM THK)12
1W05127 COVER1
7W06888 GASKET2
7W64929 PLUG-PIPE (1/2-14-THD)1
031021910 BOLT-LOCKING (3/8-16X1.75-IN)1
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)1
153548411 GASKET2
6L958912 GASKET2
5D984413 BOLT-LOCKING (3/8-16X2-IN)1
4W477514 ADAPTER2
4N419315 ADAPTER2
109007816 SEAL-O-RING2
5P720417 SEAL-O-RING2
1W487918 CORE AS-AFTERCOOLER1
8N809819 HOUSING1
8T676420 PLUG-PIPE (1/8-27-THD)3
2N820421 GASKET6
3E743022 PLUG-PIPE (3/4-14-THD)1
031021923 BOLT-LOCKING (3/8-16X1.75-IN)10
5B562024 BOLT (5/16-18X2.125-IN)22
8T676225 PLUG-PIPE (1/2-14-THD)1
1B957526 BOLT (5/16-18X1.56-IN)1
5B5620BOLT (5/16-18X2.125-IN)1
