System And Components
9Y-1595 DRIVE GP-ACCESSORY -PUMP DRIVES/N 4WJ1-410
Group No: 9Y-1595
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N3012 | 1 ADAPTER AS | 1 | |
| 3F5792 | 2 SEAL-O-RING | 1 | |
| 7N3009 | 3 CAGE AS | 1 | |
| 7N3011 | BUSHING | 1 | |
| 3F6795 | DOWEL | 2 | |
| 4P3743 | 4 SHAFT AS | 1 | |
| 9X7726 | SLEEVE-WEAR | 1 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 7N2865 | 5 GEAR-DRIVE (73-TEETH) | 1 | |
| 7N8525 | 6 WASHER-THRUST | 2 | |
| 7N2909 | 7 GEAR AS-CLUSTER (60, 50-TEETH) | 1 | |
| 7N2910 | BUSHING | 1 | |
| 7N3005 | 8 SHAFT-IDLER | 1 | |
| 5D9514 | 9 BOLT (5/8-11X6.25-IN) | 1 | |
| 7N3006 | 10 WASHER-THRUST | 2 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 5P8247 | 12 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 8M5255 | 13 SEAL-O-RING | 1 | |
| 0S1587 | 14 BOLT (1/2-13X1.75-IN) | 2 | |
| 5P2546 | 15 BOLT-12 POINT HEAD (7/16-14X1.25-IN) | 12 | |
| 1D4574 | 16 BOLT (1/2-13X6-IN) | 1 | |
| 5D3954 | 17 STUD-TAPERLOCK (5/8-11X4.4-IN) | 2 | |
| 2D8806 | 18 STUD-TAPERLOCK (1/2-13X1.87-IN) | 4 | |
| 1F7958 | 19 NUT-FULL (1/2-13-THD) | 4 | |
| 9X7711 | 20 SEAL GP (ACCESSORY DRIVE) | 1 | |
| 9X7726 | SLEEVE-WEAR | 1 | |
| 4K0367 | 21 NUT-FULL (5/8-11-THD) | 2 | |
| 1V6341 | 22 SEAL | 2 | |
| 2B0947 | 23 BOLT (1/2-13X2.25-IN) | 2 |
