System And Components
9Y-8895 DRIVE GP-AUXILIARY -LOWER, LHS/N 2PK1-550
Group No: 9Y-8895
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8M5255 | 1 SEAL-O-RING | 2 | |
| 7C3260 | 2 SHAFT | 1 | |
| 1D4572 | 3 BOLT (1/2-13X5.5-IN) | 2 | |
| 5P8245 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5R7137 | 5 WASHER-SEALING | 2 | |
| 0T0055 | 6 BOLT (3/8-16X4.25-IN) | 1 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5R7136 | 8 WASHER-SEALING | 1 | |
| 7E0275 | 9 GEAR-WATER PUMP DRIVE (69-TEETH) | 1 | |
| 4S6137 | 10 STUD-TAPERLOCK (3/8-16X3.1-IN) | 4 | |
| 7E6749 | 11 SHAFT-PUMP DRIVE | 1 | |
| 7E0274 | 12 GEAR AS-IDLER (53-TEETH) | 1 | |
| 7N5243 | 13 BUSHING | 1 | |
| 7N5246 | 14 WASHER-THRUST | 2 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 4 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 6 | |
| 1T0132 | 18 SEAL-O-RING | 1 | |
| 2M4453 | 19 SEAL-O-RING | 1 | |
| 6K3771 | 20 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 12 | |
| 7C3258 | 21 WASHER AS-THRUST | 1 | |
| 7N2047 | 22 DOWEL | 1 | |
| 7E6750 | 23 ADAPTER AS | ||
| 4D0514 | PLUG-PIPE | 1 | |
| 7N5244 | 24 BUSHING | 1 | |
| 7E6748 | 25 ADAPTER AS | 1 | |
| 9F2247 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 7N5244 | 26 BUSHING | 1 | |
| 1T0720 | 27 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 2 |
