System And Components
9Y-8899 DRIVE GP-AUXILIARY -REARS/N 2PK1-UP
Group No: 9Y-8899
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6757 | 1 PLUG-PIPE | 3 | |
| 7E6625 | 2 COVER | 1 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 6 | |
| 7X7731 | 4 PLUG-PIPE (3/4-14-THD) | 2 | |
| 7E3876 | 5 GASKET | 2 | |
| 3D0490 | 6 STUD-TAPERLOCK (1/2-13X1.97-IN) | 8 | |
| 1F7958 | 7 NUT-FULL (1/2-13-THD) | 12 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8N2802 | 9 COVER | 2 | |
| 4J6925 | 10 STUD-TAPERLOCK | 4 | |
| 0S1591 | 11 BOLT (3/8-16X1.5-IN) | 2 | |
| 9S8752 | 12 NUT-FULL (3/8-16-THD) | 2 | |
| 7E6619 | 13 HOUSING-ACCESSORY DRIVE | 1 | |
| 3F6795 | 13A DOWEL | 2 | |
| 7N3011 | 13B BUSHING | 3 | |
| 5B5821 | 13C DOWEL | 2 | |
| 1T0765 | 14 BOLT (3/8-16X1-IN) | 18 | |
| 1W4736 | 15 GASKET-COVER | 1 | |
| 1078749 | 16 GEAR-AUXILIARY DRIVE (83-TEETH) | 1 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 12 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 3F5792 | 19 SEAL-O-RING | 1 | |
| 8N2757 | 20 ADAPTER AS | 1 | |
| 7N3011 | 20A BUSHING | 1 | |
| 8M5253 | 21 SEAL-O-RING | 1 | |
| 0L1026 | 22 PLUG-CUP | 1 | |
| 4P3738 | 23 SHAFT AS | 1 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 7N8525 | 24 WASHER-THRUST | 2 | |
| 4P3834 | 25 GASKET | 1 | |
| 1T0720 | 26 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 2 | |
| 2J6274 | 27 SEAL-O-RING | 1 |
