System And Components
9Y-8917 MUFFLER GP -LH TURBOSS/N 1HL1-UP
Group No: 9Y-8917
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2428869 | 1 PIPE-EXTENSION | 1 | |
| 7E6811 | 2 MUFFLER AS | 1 | |
| 6V3823 | 3 BOLT (M12X1.75X60-MM) | 2 | |
| 6V8149 | 4 NUT (M12X1.75-THD) | 2 | |
| 2V8169 | 5 PLATE | 4 | |
| 8T0375 | 6 BOLT (M16X2X45-MM) | 4 | |
| 8X3142 | 7 PIPE-EXTENSION | 1 | |
| 6N9298 | 8 CLAMP | 1 | |
| 7E8452 | 9 CLAMP | 1 | |
| 8X3135 | 10 PLATE AS | 1 | |
| 2Y5829 | 11 NUT (M10X1.5-THD) | 3 | |
| 6V5843 | 12 BOLT (M10X1.5X45-MM) | 12 | |
| 6V5839 | 13 WASHER (11X21X2.5-MM THK) | 30 | |
| 6V6317 | 14 BOLT (M10X1.5X20-MM) | 3 | |
| 8X3128 | 15 STRAP | 3 | |
| 5T7824 | 16 CLAMP AS | 1 | |
| 6V3668 | 17 BOLT (M12X1.75X30-MM) | 2 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 12 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8X3132 | 21 BRACKET AS | 3 | |
| 6V7744 | 22 LOCKNUT (M10X1.5-THD) | 12 | |
| 6V7687 | 23 LOCKNUT (M12X1.75-THD) | 2 |
