System And Components
102-1703 WIRING GP-PLATFORM -RHS/N 1HL1-407
Group No: 102-1703
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8M2770 | 1 CLIP (LOOP) | 1 | |
| 8T4137 | 2 BOLT (M10X1.5X20-MM) | 23 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 23 | |
| 9F8125 | 3 LOCKWASHER | 6 | |
| 6V2687 | SCREW-PAN HEAD (10-24X1-IN) | 6 | |
| 9M8406 | 4 CLIP (LOOP) | 4 | |
| 6G7021 | 5 BRACKET | 1 | |
| 9G9150 | 6 CLIP | 4 | |
| 8X5741 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 7D7233 | 8 CLIP (LOOP) | 5 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P1506 | 10 HOSE (200CM) | ||
| 4K8864 | 11 CLIP (LOOP) | 1 | |
| 4D7794 | 12 CLIP | 2 | |
| 3T3048 | 13 CLIP AS | 1 | |
| 7N3718 | 14 CLIP | 1 | |
| 8K1433 | 15 GROMMET | 1 | |
| 3S2093 | 16 STRAP-CABLE | 2 | |
| 6V9672 | 17 SCREW-MACHINE (M4X0.7X16-MM) | 6 | |
| 9F5599 | LOCKWASHER | 12 | |
| 5C8312 | NUT (M4X0.7-THD) | 6 | |
| 8T9684 | 18 LAMP GP-SIGNAL (GREEN)(PAYLOAD MONITORING) | 1 | |
| 8T9683 | 19 LAMP GP-SIGNAL (RED)(PAYLOAD MONITORING) | 1 | |
| 3T3967 | 20 LAMP GP-SIGNAL (PARKING, TURN)(PARK & FRONT TURN)(AMBER) | 2 | |
| 6V7687 | 21 LOCKNUT (M12X1.75-THD) | 4 | |
| 8X7847 | ROD | 4 | |
| 5P1076 | 22 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 8T4244 | NUT (M12X1.75-THD) | 4 | |
| 8X5868 | 23 HARNESS AS (RH TURN SIGNAL) | 1 |
