System And Components
115-9179 WIRING GP-PLATFORM -RH-VIMSS/N 1HL195-399
Group No: 115-9179
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3045 | 1 CLIP AS | 1 | |
| 8T4137 | 2 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 1113794 | 4 SENSOR GP-COOLANT LEVEL (COOLANT LOSS) | 1 | |
| 3S2093 | 5 STRAP-CABLE | 4 | |
| 9G9150 | 6 CLIP (TAB) | 2 | |
| 8T4244 | 7 NUT (M12X1.75-THD) | 4 | |
| 8T4223 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 4D7794 | 9 CLIP | 2 | |
| 5P1076 | 10 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 6V7687 | 11 LOCKNUT (M12X1.75-THD) | 4 | |
| 8X7847 | 12 ROD | 4 | |
| 7D7233 | 13 CLIP (LOOP)(SLOT) | 5 | |
| 5P1506 | 14 HOSE (200CM) | ||
| 8X5868 | 15 HARNESS AS (RH TURN SIGNAL) | 1 | |
| 5C8312 | 16 NUT (M4X0.7-THD) | 6 | |
| 3T3967 | 17 LAMP GP-SIGNAL (PARKING, TURN)(PARK & FRONT TURN)(AMBER) | 2 | |
| 6V9672 | 18 SCREW-MACHINE (M4X0.7X16-MM) | 6 | |
| 9F5599 | 19 LOCKWASHER | 12 | |
| 8M2770 | 20 CLIP (LOOP) | 1 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 21 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 9M8406 | 23 CLIP (LOOP) | 4 | |
| 6G7021 | 24 BRACKET | 1 | |
| 9G9150 | 25 CLIP (TAB) | 2 | |
| 8X5741 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3S2093 | 27 STRAP-CABLE | 1 | |
| 4D7794 | 28 CLIP | 2 | |
| 3T3048 | 29 CLIP AS | 1 | |
| 4S1936 | 30 CLIP (SLOT) | 1 | |
| 8K1433 | 31 GROMMET | 1 | |
| 9F8125 | 32 LOCKWASHER | 6 | |
| 6V2687 | 33 SCREW-PAN HEAD (10-24X1-IN) | 6 | |
| 8T9684 | 34 LAMP GP-SIGNAL (GREEN)(PAYLOAD MONITORING) | 1 | |
| 8T9683 | 35 LAMP GP-SIGNAL (RED)(PAYLOAD MONITORING) | 1 | |
| 1S0994 | 36 CLIP (LOOP) | 5 | |
| 1157464 | 37 HARNESS AS (VIMS)(JACKET WATER) | 1 | |
| 4K8864 | 38 CLIP (LOOP)(CIRCULAR) | 1 |
