System And Components
8N2235 LINES GP-TURBOCHARGER OIL
Group No: 8N2235
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B1915 | 1 BOLT (3/8-16X1.375IN) | 2 | |
| 1S6595 | 2 GASKET | 1 | |
| 1N2909 | 3 TUBE AS-OIL | 1 | |
| 1S4810 | 4 GASKET-OIL DRAIN | 1 | |
| 1A2029 | 5 BOLT (3/8-16X1.125IN) | 5 | |
| 5M2894 | 6 WASHER (2.5MM THK) | 4 | |
| 6N6033 | 7 CLIP | 2 | |
| 1D4716 | 8 NUT-FULL (5/16-18 THD) | 1 | |
| 8M0505 | 9 CONNECTOR | 1 | |
| 3K0360 | 10 SEAL-O-RING (16.36MM ID) | 2 | |
| 8M5253 | 11 SEAL (18.72MM ID) | 1 | |
| 5M6213 | 12 PLUG | 1 | |
| 4W1512 | 13 SUPPORT AS-PUMP | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8M5248 | 14 SEAL-O-RING (28.17 ID) | 2 | |
| 9S8002 | 15 PLUG-O-RING (7/16-20 THD) | 1 | |
| 3J7354 | SEAL-O-RING (8.92MM ID) | 1 | |
| 4M6480 | 16 GASKET | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25IN) | 1 | |
| 8N1149 | 18 ELBOW | 1 | |
| 9M4849 | SEAL-O-RING (23.16 ID) | 1 | |
| 9S4185 | 19 PLUG-O-RING (3/4-16 THD) | 1 | |
| 1N2911 | 20 TUBE AS-OIL DRAIN | 1 | |
| 0S1617 | 21 BOLT (5/16-18X.75IN) | 1 | |
| 9M1974 | 22 WASHER-HARD | 2 |
