System And Components
5R4412 GEAR GP-REAR-PART 2 OF 2
Group No: 5R4412
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5F7404 | 21 LOCKNUT-BEARING | 1 | |
| 5F7403 | 22 LOCK-NUT | 1 | |
| 5P1370 | 23 BEARING AS-ROLLER | 2 | |
| 5P8429 | 24 SEAL-O-RING | 2 | |
| 4N7183 | 25 RING-RETAINER | 2 | |
| 1T0720 | 26 BOLT-12 POINT HEAD (3/8-16X1.25IN) | 12 | |
| 2W7609 | 27 GEAR (64 TEETH) | 1 | |
| 1A2029 | 28 BOLT (3/8-16X1.125IN) | 4 | |
| 5M2894 | 29 WASHER (2.5MM THK) | 8 | |
| 4N1232 | 30 WASHER-RETAINER | 1 | |
| 2W7610 | 31 GEAR (64 TEETH) | 1 | |
| 4N1720 | 32 COVER-BALANCE WEIGHT | 1 | |
| 3G2292 | 33 BOLT-LOCKING | 4 | |
| 4N0848 | 34 SLEEVE-WEAR | 1 | |
| 5K9065 | 35 RING-RETAINING (5.4MM OD) | 2 | |
| 6V3319 | 36 SEAL-O-RING (158.34MM ID) | 1 | |
| 6V7423 | 37 BEARING AS-ROLLER | 2 | |
| 1D4566 | 38 BOLT (1/2-13X3.5IN) | 8 | |
| 2D6398 | 39 RING-RETAINING | 1 | |
| 7N1565 | 40 ADAPTER | 1 | |
| 7N1564 | 41 WASHER-THRUST | 1 | |
| 0L1351 | 42 BOLT (3/8-16X.875IN) | 2 | |
| 4N1186 | 43 BEARING-SLEEVE | 2 | |
| 9X7371 | 44 SEAL-O-RING (126.59MM ID) | 1 | |
| 8N0935 | 45 GEAR (22 TEETH) | 1 | |
| 1B9575 | 46 BOLT (5/16-18X1.75IN) | 4 | |
| 2W8038 | 47 GEAR-CAMSHAFT (44 TEETH) | 1 |
