System And Components
1W9881 LINES GP-AIRENGINE S/N 48W36700-99999
Group No: 1W9881
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N2493 | 1 ELBOW-EXHAUST | 1 | |
| 9S2592 | 2 HOSE-HUMP | 1 | |
| 5P3860 | 3 CLAMP-HOSE | 2 | |
| 1V6566 | 4 PIPE AS-AIR TRANSFER | 1 | |
| 7M1674 | ELEMENT-FILTER | 1 | |
| 0L0765 | STUD | 10 | |
| 6N4247 | 5 ELBOW-EXHAUST | 1 | |
| 8T8917 | 6 BOLT | 4 | |
| 8T4223 | 7 WASHER-HARD | 4 | |
| 7N0694 | 8 ELBOW-MUFFLER INLET | 1 | |
| 6L8562 | 9 STUD-TAPERLOCK | 4 | |
| 1B5355 | 10 NUT-FULL | 12 | |
| 5M2894 | 11 WASHER | 16 | |
| 6N4248 | 12 BRACKET | 1 | |
| 0S1571 | 13 BOLT | 4 | |
| 6N4249 | 14 ELBOW-OUTLET | 1 | |
| 2N2765 | BOLT-HIGH TEMPERATURE | 4 | |
| 2N2766 | LOCKNUT | 4 | |
| 9Y8968 | 15 COUPLING-EXHAUST | 1 | |
| 5L8854 | 16 RING-SEALING | 2 | |
| 9M1869 | 17 PIPE-AIR TRANSFER | 1 | |
| 2M5173 | 18 SEAL-O-RING | 4 | |
| 8T2502 | 19 BOLT | 3 | |
| 1W9882 | 20 ELBOW-COMPRESSOR INLET | 1 | |
| 8N5527 | 21 BRACKET AS-ELBOW | 1 | |
| 4L6454 | 22 BOLT | 2 | |
| 0S1591 | 23 BOLT | 4 | |
| 3B6552 | 24 ELBOW | 2 | |
| 8T4896 | 25 WASHER-HARD | 5 | |
| 1240369 | 26 PIPE | 1 | |
| 1240368 | 27 PIPE | 1 | |
| 6V3970 | 28 GROMMET | 1 | |
| 8B4884 | 29 ELBOW | 1 | |
| 1W0613 | 30 INDICATOR-AIR FILTER SERVICE | 1 |
