System And Components
139-7442 CONVERSION GP-BREATHERS/N 6BL858-UP
Group No: 139-7442
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1293563 | 1 COVER AS-VALVE | 1 | |
| 1051846 | SEAL | 1 | |
| 1266671 | GASKET (VALVE COVER) | 1 | |
| 1272694 | COVER | 1 | |
| 1272695 | GASKET | 1 | |
| 1272696 | FOAM (CRANKCASE BREATHER) | 1 | |
| 1272698 | BAFFLE | 3 | |
| 1272699 | BOLT | 14 | |
| 1272701 | INSERT | 14 | |
| 1272702 | VALVE (FUMES DISPOSAL) | 1 | |
| 1272704 | SEAL-O-RING | 1 | |
| 1272705 | SEAL-O-RING | 1 | |
| 1298347 | ELBOW | 1 | |
| 1363608 | CAP AS (ENGINE OIL FILLER) | 1 | |
| 1240506 | SEAL | 1 | |
| 2S3440 | 2 CLAMP-HOSE | 3 | |
| 5P0765 | 3 HOSE (40CM) | ||
| 1398288 | 4 PLATE | 1 | |
| 5K9660 | 5 CLIP (LOOP) | 1 | |
| 8T4136 | 6 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4133 | 7 NUT (M10X1.5-THD) | 1 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 1397441 | 9 PIPE | 1 | |
| 1398286 | 10 PIPE AS | 1 | |
| 6V1889 | 11 CLIP (LOOP) | 1 | |
| 1313701 | 12 HOSE | 1 | |
| 1411710 | 13 GASKET | 1 | |
| 1422414 | 14 GASKET | 1 |
