8N-9267 CYLINDER BLOCK GPS/N 11N8496-99999

Group No: 8N-9267

Part Number	Part Name	Qty
7W4990	1 JET AS-PISTON COOLING	6
8T6757	2 PLUG-PIPE	3
7W6534	3 PLUG-PIPE	1
2W6000	4 LINER-CYLINDER BLOCK	6
8T6763	5 PLUG-PIPE (1/4-18-THD)	3
1S9540	6 DOWEL	2
3S5496	7 SEAL-O-RING	2
7W6492	8 PLUG-PIPE (1/2-14-THD)	1
0307571	9 BOLT (3/8-16X1-IN)	4
4W8585	10 COVER	1
7W6081	11 GASKET	1
9X7378	12 SEAL-O-RING	1
4N0683	13 DOWEL	4
4N1650	14 DOWEL	2
6I2981	15 PLATE-BLOCK	1
6I4024	16 GASKET-PLATE	1
8S9094	17 PLUG-ORIFICE	1
9S4190	18 PLUG-O-RING (7/8-14-THD)	1
1144427	19 SEAL-O-RING	1
7X7732	20 PLUG-PIPE	6
1118606	21 BOLT-SPECIAL (OIL JET)	6
4N0685	22 BUSHING (1-IN WIDE)	6
4N6658	23 BUSHING (1.3-IN WIDE)	1
8T6764	24 PLUG-PIPE (1/8-27-THD)	1
9S8009	25 PLUG-O-RING	1
1195155	26 SEAL-O-RING	1
1102220	27 SEAL-LINER	6
1427072	27A SEAL-LINER	6
1426217	27B SEAL-O-RING	6
3P1323	28 BOLT-BEARING CAP (7/8-14X7.75-IN)	14
9H1031	29 WASHER-HARD (24X41.5X6-MM THK)	14
4N5857	30 CAP-CRANKSHAFT BEARING	7
9L5854	31 BAND-FILLER (130.2-MM ID)	6
4W4588	32 SLEEVE-LIFTER BORE
4W6061	SLEEVE
9S4190	33 PLUG-O-RING (7/8-14-THD)	1
1144427	34 SEAL-O-RING	1
1007399	35 PLUG	2
3E6747	36 SEAL-O-RING	2
9S4182	37 PLUG (7/16-20-THD)	1
5N0093	INSERT-LINER SEAT (2.71-MM THK)(2.7MM THK)
2W3815	INSERT-LINER SEAT (1.605-MM THK)(1.59MM THK)
9Y3368	INSERT-LINER SEAT (0.822-MM THK)(0.82MM THK)
