System And Components
7E-4697 CYLINDER BLOCK GPS/N 1DL1-UP; 41Z19826-UP
Group No: 7E-4697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1515928 | 1 JET AS-PISTON COOLING | 6 | |
| 8T6757 | 2 PLUG-PIPE | 3 | |
| 7W6534 | 3 PLUG-PIPE | 1 | |
| 8T6763 | 5 PLUG-PIPE (1/4-18-THD) | 3 | |
| 1S9540 | 6 DOWEL | 2 | |
| 3S5496 | 7 SEAL-O-RING | 2 | |
| 7W6492 | 8 PLUG-PIPE (1/2-14-THD) | 1 | |
| 0307571 | 9 BOLT (3/8-16X1-IN) | 4 | |
| 4W8585 | 10 COVER | 1 | |
| 7W6081 | 11 GASKET | 1 | |
| 3048008 | 12 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 4N0683 | 13 DOWEL | 4 | |
| 4N1650 | 14 DOWEL | 2 | |
| 6I2981 | 15 PLATE-BLOCK | 1 | |
| 6I4024 | 16 GASKET-PLATE | 1 | |
| 8S9094 | 17 PLUG-ORIFICE | 1 | |
| 3535125 | 19 PLUG AS | 2 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 7X7732 | 20 PLUG-PIPE | 6 | |
| 1515925 | 21 BOLT (7/16-14-THD) | 6 | |
| 8T6764 | 24 PLUG-PIPE (1/8-27-THD) | 1 | |
| 2021258 | 25 CYLINDER BLOCK GP | 1 | |
| 3535141 | 26 PLUG AS | 1 | |
| 9S8009 | PLUG-O-RING | 1 | |
| 2918145 | SEAL-O-RING | 1 | |
| 2M6471 | 27 PLUG-CUP | 2 | |
| 1010523 | INSERT-LINER SEAT (5.21-MM THK) | ||
| 1010524 | INSERT-LINER SEAT (5.16-MM THK)(0.5-MM US) | ||
| 1010525 | INSERT-LINER SEAT (5.26-MM THK)(0.5-MM OS) |
