System And Components
4P-9858 GEAR GP-FRONTS/N 6NC1-99999; 4YK1-UP; 08Z89612-99999
Group No: 4P-9858
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N2602 | 1 BOLT (5/8-11X2-IN) | 1 | |
| 7N2994 | 2 WASHER (49.3X16.25X12.3-MM THK) | 1 | |
| 8N4960 | 3 PLATE-THRUST | 1 | |
| 0S1618 | 4 BOLT (5/16-18X1-IN) | 2 | |
| 1707502 | 5 SHAFT-DRIVE IDLER | 1 | |
| 0S1748 | 6 BOLT (3/8-24X2-IN) | 4 | |
| 5M2894 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1960224 | 8 GEAR AS-IDLER (50-TEETH) | 1 | |
| 1969988 | BUSHING | 1 | |
| 4P7826 | 9 GEAR-CAMSHAFT (66-TEETH) | 1 | |
| 4P7822 | 10 WEIGHT AS | 1 | |
| 9N5766 | 10A WEIGHT | 2 | |
| 1W5879 | 10B SPRING (54.6MM LONG) | 2 | |
| 1W5878 | 10C SPRING (35.7MM LONG) | 2 | |
| 9N5767 | 10D SLIDE | 2 | |
| 9N5765 | 10E PLATE-END | 1 | |
| 4B1273 | 10F SCREW-MACHINE (10-24X0.5-IN) | 2 | |
| 8N0498 | 10G SEAL-FACE | 1 | |
| 6F4718 | 10H SEAL-O-RING | 1 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 2 | |
| 1960028 | 12 GEAR AS-IDLER (47-TEETH) | 1 | |
| 1950302 | BUSHING | 1 | |
| 5B9079 | 13 NUT-JAM (3/8-24-THD) | 1 |
