Assembly
100%

1W-1468 HOUSING GP-FRONTS/N 1DL1-UP; 11N7400-99999; 41Z1-UP

Group No: 1W-1468
Part NumberPart NameQty
1W14691 HOUSING AS-GEAR1
3K32561A STUD-TAPERLOCK (3/8-16X1.7-IN)4
8T67641B PLUG-PIPE (1/8-27-THD)1
4M27431C STUD-TAPERLOCK (3/8-16-THD)3
4M27431D STUD-TAPERLOCK (3/8-16-THD)2
3K32561E STUD-TAPERLOCK (3/8-16X1.7-IN)1
6H0406STUD-TAPERLOCK (3/8-16X1.968-IN)1
1A20292 BOLT (3/8-16X1.125-IN)4
1W14713 PLATE1
16691424 GASKET1
16691465 GASKET1
9S87526 NUT-FULL (3/8-16-THD)1
5P42557 BOLT-LOCKING (3/8-16X1-IN)8
0L13528 BOLT (3/8-16X3.25-IN)2
0T00559 BOLT (3/8-16X4.25-IN)3
5M289410 WASHER-HARD (10.2X18.5X2.5-MM THK)18
1N318111 STUD-HOLLOW (3/8-16X1.476-IN)2
6B2250GASKET2
6N038912 STUD (1/2-13X2.63-IN)1
4H6145GASKET1
