System And Components
108-4855 CONTROL & WIRING GP-AUGERS/N 1DL1-UP
Group No: 108-4855
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9D3721 | 1 SWITCH-TOGGLE (SINGLE POLE) | 1 | |
| 6T6969 | 2 GUARD-SWITCH | 1 | |
| 3E6449 | 3 SWITCH AS-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3K0360 | 4 SEAL-O-RING | 1 | |
| 3S2093 | 5 STRAP-CABLE | 5 | |
| 4D7794 | 6 CLIP | 7 | |
| 8T2502 | 7 BOLT (3/8-16X1.125-IN) | 4 | |
| 9G9150 | 8 CLIP | 3 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 6V8801 | 10 NUT (3/8-16-THD) | 4 | |
| 1090260 | 11 SWITCH AS-PRESSURE | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5F9144 | SEAL-O-RING | 1 | |
| 1105982 | 12 BRACKET | 1 | |
| 1095901 | 13 FILM-INSTRUCTION | 1 | |
| 1484469 | 14 HARNESS AS | 1 | |
| 8M2770 | 15 CLIP (LOOP) | 2 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 4 | |
| 1142833 | 17 HARNESS AS | 1 | |
| 4L9337 | 18 BOLT (3/8-16X1.5-IN) | 1 | |
| 5S7382 | 19 BOLT (3/8-16X1.375-IN) | 1 |
