Assembly
100%

116-5970 PUMP GP-FUEL TRANSFERS/N 8HK1-UP; 9FL1-UP

Group No: 116-5970
Part NumberPart NameQty
00391631 ELBOW1
6D35342 CONNECTOR-HOSE2
2S34403 CLAMP-HOSE4
00472704 FITTING-PIPE1
4S19625 CLIP (LOOP)4
8T41376 BOLT (M10X1.5X20-MM)4
8T41217 WASHER-HARD (11X21X2.5-MM THK)6
5C61088 SWITCH GP-REFUELING (FUEL TANK SHUTOFF)1
6C55729 PUMP & MOTOR GP-REFUELING1
8T419210 BOLT (M12X1.75X25-MM)4
8T422311 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422412 WASHER-HARD (8.8X16X2-MM THK)2
7X253713 BOLT (M8X1.25X35-MM)2
4I006214 COVER1
8T413315 NUT (M10X1.5-THD)2
5P074316 HOSE
5P074217 HOSE (350 CM)
5C074618 STRAINER GP-FUEL1
7I153719 SUPPORT AS1
4I844320 VALVE-CHECK1
7I084521 CONNECTOR1
3B772822 ELBOW1
005789823 CONNECTOR-HOSE1
9K070024 GROMMET1
6B908125 BUSHING-REDUCER1
006570726 ELBOW-PIPE1
