System And Components
8N-0246 CYLINDER HEAD GPS/N 6NC1-99999; R6J1-UP; 08Z73070-99999
Group No: 8N-0246
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S7144 | 1 SPRING-VALVE | 12 | |
| 1W5300 | 2 ROTOCOIL AS | 12 | |
| 6N7174 | SHIELD-OIL | 1 | |
| 2A4429 | 3 LOCK-RETAINER | 24 | |
| 7N8018 | 4 SEAL | 6 | |
| 9Y1798 | 5 SEAL | 18 | |
| 1487455 | 6 VALVE-EXHAUST | 6 | |
| 1007860 | 7 VALVE-INLET | 6 | |
| 1118015 | 8 GASKET AS-CYLINDER HEAD | 1 | |
| 3B0623 | 9 PLUG-CUP | 6 | |
| 3S8313 | 10 PLUG-CUP | 7 | |
| 3S5496 | 11 SEAL-O-RING | 1 | |
| 8T6763 | 12 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1070268 | 13 INSERT-VALVE SEAT (INLET)(STANDARD) | 6 | |
| 1118021 | INSERT-VALVE SEAT (0.13-MM OS, INLET) | ||
| 1118022 | INSERT-VALVE SEAT (0.25-MM OS, INLET) | ||
| 1118023 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 1118024 | INSERT-VALVE SEAT (0.76-MM OS, INLET) | ||
| 1070265 | 14 INSERT-VALVE SEAT (EXHAUST)(STANDARD) | 6 | |
| 1118025 | INSERT-VALVE SEAT (0.13-MM OS, EXHAUST) | ||
| 1118026 | INSERT-VALVE SEAT (0.25-MM OS, EXHAUST) | ||
| 1118027 | INSERT-VALVE SEAT (0.51-MM OS, EXHAUST) | ||
| 1118028 | INSERT-VALVE SEAT (0.76-MM OS, EXHAUST) | ||
| 1487425 | 15 GUIDE-VALVE (STANDARD) | 12 | |
| 1546997 | GUIDE-VALVE (0.51-MM OS) | ||
| 1546998 | GUIDE-VALVE (0.13-MM OS) | ||
| 3P1896 | 16 PLUG-CUP | 13 | |
| 8T6762 | 17 PLUG-PIPE (1/2-14-THD) | 3 |
