System And Components
108-2702 LINES GP-TURBOCHARGER OILS/N R6J1-UP; 08Z73070-86459
Group No: 108-2702
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B1915 | 1 BOLT (3/8-16X1.375-IN) | 2 | |
| 1S6595 | 2 GASKET-OIL SUPPLY | 1 | |
| 1S4810 | 3 GASKET-OIL DRAIN | 1 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 5 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 1N2911 | 6 TUBE AS-OIL DRAIN | 1 | |
| 1B3057 | 7 CLIP | 1 | |
| 2N2766 | 8 LOCKNUT (3/8-16-THD) | 1 | |
| 5P7128 | 9 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 1 | |
| 8N1149 | 10 ELBOW | 1 | |
| 4M6480 | 11 GASKET | 1 | |
| 0L2070 | 12 BOLT (3/8-16X2.25-IN) | 1 | |
| 9M4849 | 13 SEAL-O-RING | 1 | |
| 6K3607 | 14 CONNECTOR | 1 | |
| 2M9780 | 15 SEAL-O-RING | 1 | |
| 3K0360 | 16 SEAL-O-RING | 2 | |
| 1082699 | 17 TUBE AS | 1 | |
| 4W1512 | 18 SUPPORT AS-PUMP | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4185 | 19 PLUG (3/4-16-THD) | 2 | |
| 8M5253 | 20 SEAL-O-RING | 1 | |
| 9S8002 | 21 PLUG (7/16-20-THD) | 1 | |
| 8T6765 | 22 PLUG-PIPE (1/4-18-THD) | 1 | |
| 3J7354 | 23 SEAL-O-RING | 1 | |
| 1025868 | 24 HOSE AS | 1 | |
| 9M1974 | 25 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 1240174 | 26 CLIP (LOOP) | 1 | |
| 1C0569 | 27 BOLT (5/16-18X0.5-IN) | 1 | |
| 8M5248 | 28 SEAL-O-RING | 2 |
