System And Components
6I-2890 LINES GP-TURBOCHARGER OILS/N 6NC1-99999; R6J1-UP; 08Z86460-99999
Group No: 6I-2890
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I2892 | 1 TUBE AS-OIL | 1 | |
| 1094733 | 2 TUBE AS-OIL | 1 | |
| 0S1594 | 3 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1886126 | 5 GASKET | 1 | |
| 4M6480 | 6 GASKET | 1 | |
| 9M4849 | 7 SEAL-O-RING | 1 | |
| 9N5328 | 8 ADAPTER | 1 | |
| 0S1618 | 9 BOLT (5/16-18X1-IN) | 2 | |
| 8H9788 | 10 GASKET | 1 | |
| 4W1512 | 11 SUPPORT AS-PUMP | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4185 | 12 PLUG (3/4-16-THD) | 2 | |
| 3K0360 | 13 SEAL-O-RING | 2 | |
| 8M5253 | 14 SEAL-O-RING | 1 | |
| 8M5248 | 15 SEAL-O-RING | 2 | |
| 9S8002 | 16 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 17 SEAL-O-RING | 1 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 3 | |
| 0L1143 | 20 BOLT (3/8-16X2.5-IN) | 1 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M8406 | 22 CLIP (LOOP) | 1 | |
| 1B9575 | 23 BOLT (5/16-18X1.56-IN) | 1 | |
| 9M4584 | 24 CONNECTOR | 1 | |
| 2M9780 | 25 SEAL-O-RING | 1 | |
| 3E4352 | 26 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 |
