130-2225 AFTERCOOLER GP-WATERS/N 6NC1-99999; 08Z77420-99999

Group No: 130-2225
Part NumberPart NameQty
12616891 COVER AS1
1H6525INSERT4
1H55142 BOLT (5/16-18X1.625-IN)20
9M19743 WASHER-HARD (8.8X16X2-MM THK)24
9L59084 GASKET2
7W04915 CORE AS-AFTERCOOLER1
5S67356 GASKET2
8T67627 PLUG-PIPE (1/2-14-THD)1
03102198 BOLT-LOCKING (3/8-16X1.75-IN)4
5M28949 WASHER-HARD (10.2X18.5X2.5-MM THK)15
126168810 HOUSING1
9L590311 ADAPTER2
6L164812 SEAL-O-RING2
2W367913 GASKET2
9L262514 FLANGE-TRANSFER PIPE1
0L207015 BOLT (3/8-16X2.25-IN)3
1N937216 GASKET-FLANGE (AIR INLET)1
034355717 BOLT-LOCKING (3/8-16X1.125-IN)4
4N020518 SPACER (0.42X0.75X0.6-IN THK)4
8T676519 PLUG-PIPE (1/4-18-THD)1
2B269420 BOLT (5/16-18X2-IN)4
119134221 BRACKET2
