System And Components
2W8361 LINES GP-ENGINE OIL-PART 1 OF 2
Group No: 2W8361
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0321268 | 1 ELBOW | 1 | |
| 8N7806 | 2 HOSE AS | 1 | |
| 0308194 | 3 CONNECTOR-FLARED | 1 | |
| 1144427 | 4 SEAL-O-RING | 1 | |
| 0S1594 | 5 BOLT | 7 | |
| 1090076 | 6 SEAL-O-RING | 3 | |
| 2P3760 | 7 GASKET | 1 | |
| 1A2029 | 8 BOLT | 4 | |
| 5M2894 | 9 WASHER | 9 | |
| 4N0933 | 10 GASKET | 1 | |
| 1090078 | 11 SEAL-O-RING | 2 | |
| 6N0452 | 12 ELBOW-COOLER OUTLET | 1 | |
| 2P3761 | 13 COVER | 1 | |
| 4N8150 | 14 SPRING | 1 | |
| 9M0853 | 15 PLUNGER-RELIEF VALVE | 1 | |
| 0L2070 | 16 BOLT | 3 | |
| 6N0624 | 17 TUBE AS-OUTLET | 1 | |
| 6N0448 | 18 BODY-VALVE & INLET | 1 | |
| 9Y1650 | 19 TUBE AS-OIL | 1 | |
| 0S1571 | 20 BOLT | 1 | |
| 0S1590 | 21 BOLT | 1 | |
| 1295225 | 22 SUPPORT-SUCTION BELL | 1 | |
| 4N0914 | 23 CLIP | 1 | |
| 4N0913 | 24 SCREEN AS-BELL | 1 | |
| 8N2104 | 25 BELL AS-SUCTION | 1 | |
| 9F2978 | NUT-WELD | 2 | |
| 0L1351 | 26 BOLT | 2 | |
| 8N6740 | 27 RETAINER | 2 | |
| 6N7332 | 28 TUBE AS-PUMP SUCTION | 1 | |
| 1L0509 | 29 BOLT | 1 | |
| 9N1627 | 30 WASHER | 1 | |
| 8J4351 | 31 SEAL-O-RING | 1 | |
| 8C3446 | 32 VALVE-FLUID SAMPLING | 1 | |
| 8C3445 | CAP-DUST | 1 | |
| 9X7378 | SEAL-O-RING | 1 |
