System And Components
9P-0187 AIR CONDITIONER GPS/N 63W4200-UP
Group No: 9P-0187
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 2G1949 | 2 CUSHION-SEAT | 1 | |
| 2N3680 | 3 SCREW-HEAD (1/4-20X0.75-IN) | 12 | |
| 5P0537 | 4 WASHER-HARD (7.2X14.5X2-MM THK) | 14 | |
| 2G1946 | 5 FILTER ELEMENT-CAB AIR | 1 | |
| 9G1238 | 6 HOUSING | 1 | |
| 2G0395 | 7 TUBE | 1 | |
| 2G0412 | 8 GROMMET | 2 | |
| 2G1951 | 9 CORE | 1 | |
| 6G0698 | 10 BRACKET | 2 | |
| 1B4330 | 11 NUT (1/4-20-THD) | 6 | |
| 2G0413 | 12 RESISTOR (BLOWER MOTOR) | 2 | |
| 9G1182 | 13 BRACKET | 2 | |
| 7G0661 | 14 WHEEL AS-BLOWER | 2 | |
| 4D6624 | 15 WASHER | 2 | |
| 1M1230 | 16 NUT-LOCKING (10-32-THD) | 6 | |
| 9G0397 | 17 MOTOR AS (27 VOLT) | 2 | |
| 4S1988 | TERMINAL-BLADE (14-GA TO 16-GA) | 1 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 1 | |
| 9G0398 | KIT-MOTOR BRUSH | 1 | |
| 8S0932 | 18 VALVE AS-CONTROL | 1 | |
| 2G0391 | 19 SCREW | 1 | |
| 2G1947 | 20 CONTROL AS | 1 | |
| 1V6653 | 21 SWITCH AS-TOGGLE (BLOWER MOTOR) | 2 | |
| 9P2121 | STRAP | 3 | |
| 2G1943 | 22 CABLE (67.2CM LG) | 1 | |
| 2G1945 | CABLE (46.8CM LG) | 1 | |
| 2G1944 | CABLE (54.5CM LG) | 1 | |
| 2G1942 | 23 LAMP (24-VOLT) | 1 | |
| 2G1952 | 24 COIL-EVAPORATOR | 1 | |
| 2G0396 | 25 SWITCH (REFRIGERANT PRESSURE) | 1 | |
| 4B4274 | 26 WASHER (5.5X13X1.2-MM THK) | 4 | |
| 2G0401 | 27 VALVE | 1 | |
| 7G0942 | 28 PLATE-ORIFICE | 2 | |
| 9P0220 | 29 HARNESS AS | 1 | |
| 8P3824 | 30 HOUSING | 2 | |
| 6N8589 | 31 CIRCUIT BREAKER AS (15-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 4B1222 | SCREW-MACHINE (8-32X15.88IN) | 2 |
