System And Components
6I-3745 GEAR GP-FRONT -TIMINGS/N 48W37000-UP
Group No: 6I-3745
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B2695 | 1 BOLT (5/16-18X0.875-IN) | 4 | |
| 1129217 | 2 PLATE-THRUST | 1 | |
| 1008178 | 3 GEAR AS-IDLER | 1 | |
| 1008180 | BUSHING | 1 | |
| 2W3875 | 4 GEAR-OIL PUMP DRIVE (56-TEETH) | 1 | |
| 1P7346 | 5 WASHER-HARD (10.2X35X6-MM THK) | 1 | |
| 0S1571 | 6 BOLT (3/8-16X1.75-IN) | 1 | |
| 1B8705 | 7 KEY-WOODRUFF | 1 | |
| 5M2894 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 1008181 | 9 SHAFT AS-IDLER | 1 | |
| 4H1641 | PIN-SPRING | 1 | |
| 7S5005 | DOWEL | 2 | |
| 3B1915 | 10 BOLT (3/8-16X1.375-IN) | 2 | |
| 6N1027 | 11 PLATE-THRUST | 1 | |
| 0T0573 | 12 BOLT (3/8-16X2.75-IN) | 1 | |
| 6I3750 | 13 GEAR AS-IDLER & WEIGHT | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 4N0343 | BUSHING | 1 | |
| 1179712 | 14 SHAFT-DRIVE IDLER | 1 | |
| 3G2292 | 15 BOLT-LOCKING (3/8-16X0.87-IN) | 5 | |
| 7N2443 | 16 WASHER-THRUST (2.508X3.5X0.188-IN THK) | 1 |
