System And Components
8W-9888 LINES GP-STEERINGS/N 3BJ200-278
Group No: 8W-9888
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G9209 | 1 TUBE AS | 1 | |
| 4J0524 | 2 SEAL-O-RING | 2 | |
| 4J5140 | 3 SEAL-O-RING | 8 | |
| 1P4574 | 4 FLANGE-HALF | 12 | |
| 6V5782 | 5 BOLT (5/16-18X1.125-IN) | 24 | |
| 8T4224 | 6 WASHER-HARD (8.8X16X2-MM THK) | 31 | |
| 2G3387 | 7 HOSE AS | 1 | |
| 7X0440 | 8 BOLT (5/16-18X1.75-IN) | 7 | |
| 5K9090 | 9 SEAL-O-RING | 3 | |
| 8W9945 | 10 HOSE AS | 1 | |
| 2G3385 | 11 HOSE AS | 1 | |
| 9J5385 | 12 VALVE GP-FLOW CONTROL | 1 | |
| 7X0293 | 13 BOLT (3/8-16X4.75-IN) | 3 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 2G0064 | 15 BLOCK | 2 | |
| 8W9946 | 16 HOSE AS | 1 | |
| 6V9853 | 17 ELBOW | 1 | |
| 8T0078 | CONNECTOR | 1 | |
| 6V9007 | 18 ELBOW | 1 | |
| 3D2824 | 19 SEAL-O-RING | 2 | |
| 8W9948 | 20 HOSE AS | 1 | |
| 2G8895 | 21 BRACKET AS | 1 | |
| 1F0750 | 21A NUT-WELD (3/8-16-THD) | 1 | |
| 5S7379 | 22 BOLT (3/8-16X0.875-IN) | 1 | |
| 8W9949 | 23 HOSE AS | 1 | |
| 9T3097 | 24 VALVE GP-CHECK | 1 | |
| 7M8485 | 25 SEAL-O-RING | 1 | |
| 6G9208 | 26 TUBE AS | 1 | |
| 8T9384 | 27 BOLT (1/2-13X0.875-IN) | 1 | |
| 8T8917 | 28 BOLT (1/2-13X1.25-IN) | 1 | |
| 9K2522 | 29 CLIP | 2 | |
| 9X8250 | 30 CLIP (LOOP) | 2 | |
| 2G8566 | 31 PLATE AS | 1 | |
| 9G5742 | BOSS (3/8-16-THD) | 1 | |
| 9B1006 | 31A WASHER | 2 | |
| 8D3508 | 31B BOSS (3/8-16X1-IN) | 1 | |
| 8X9341 | 32 HOSE AS | 1 | |
| 2G3161 | 33 TUBE AS | 1 | |
| 4J0525 | 34 SEAL-O-RING | 1 | |
| 7X0325 | 35 BOLT (1/2-13X2.5-IN) | 2 | |
| 8C4436 | 36 BOLT (1/2-13X1.375-IN) | 2 | |
| 8X9342 | 37 HOSE AS | 1 | |
| 4J0522 | 38 SEAL-O-RING | 1 | |
| 1P4578 | 39 FLANGE-HALF | 2 | |
| 7X0308 | 40 BOLT (7/16-14X1.375-IN) | 4 | |
| 6G3305 | 41 HOSE AS | 1 | |
| 8T5360 | 42 WASHER (12X22.5X2.5-MM THK) | 4 | |
| 8T4223 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6V8801 | 44 NUT (3/8-16-THD) | 1 | |
| 5P1075 | 45 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 6V9746 | 46 SEAL-O-RING | 3 | |
| 5P7468 | 47 CLIP (SLOT) | 2 | |
| 5P7469 | 48 CLIP (TAB) | 2 | |
| 5S7383 | 49 BOLT (3/8-16X1.75-IN) | 1 | |
| 5P7467 | 50 CLIP (TAB) | 1 | |
| 5P7464 | 51 CLIP (SLOT) | 1 | |
| 5P7465 | 52 CLIP (TAB) | 1 | |
| 6V1249 | 53 GROMMET (22-MM ID) | 1 | |
| 7X0274 | 54 BOLT (5/16-18X2.75-IN) | 1 | |
| 7X0579 | 55 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 6H7127 | 56 SPACER (13/32X5/8X9/16-IN THK) | 1 | |
| 5P7466 | 57 CLIP (SLOT) | 1 | |
| 4J0524 | 58 SEAL-O-RING | 4 | |
| 5K9090 | 59 SEAL-O-RING | 2 | |
| 5P7469 | 60 CLIP (TAB) | 5 | |
| 8T4896 | 61 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 3D2824 | 62 SEAL-O-RING | 3 | |
| 5S7379 | 63 BOLT (3/8-16X0.875-IN) | 3 | |
| 7M8485 | 64 SEAL-O-RING | 1 | |
| 5P8444 | 65 GROMMET (37-MM ID) | 4 | |
| 5P2566 | 66 BOLT (1/2-13X1.5-IN) | 12 | |
| 4J0522 | 67 SEAL-O-RING | 1 | |
| 1P4579 | 68 FLANGE-HALF | 6 | |
| 8T4223 | 69 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 5P4499 | 70 ADAPTER | 1 | |
| 8C3446 | 71 VALVE-SAMPLING | 1 | |
| 8C3451 | 72 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 3J7354 | 73 SEAL-O-RING | 1 | |
| 5P7466 | 74 CLIP (SLOT) | 6 | |
| 5M3062 | 75 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P7468 | 76 CLIP (SLOT) | 5 | |
| 8T7008 | 77 BOLT (3/8-16X3-IN) | 2 | |
| 6V8801 | 78 NUT (3/8-16-THD) | 3 | |
| 3G4667 | 79 VALVE GP-RELIEF (CYLINDER OIL CROSSOVER) | 1 | |
| 6V9008 | 80 ELBOW (90-DEG) | 1 | |
| 6V9854 | 81 ELBOW (SWIVEL) | 1 | |
| 8X0459 | 82 HOSE AS | 2 | |
| 6V8398 | 83 SEAL-O-RING | 2 | |
| 8T5429 | 84 ELBOW | 2 | |
| 5S7382 | 85 BOLT (3/8-16X1.375-IN) | 1 | |
| 6V9746 | 86 SEAL-O-RING | 2 | |
| 5P1075 | 87 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 4L6454 | 88 BOLT (3/8-16X1-IN) | 12 | |
| 5P8112 | 89 GROMMET | 6 | |
| 8W9505 | 90 GUARD | 1 | |
| 8M1047 | 91 STUD-TAPERLOCK (3/8-16X1.67-IN) | 1 | |
| 6G3384 | 92 SHIELD | 1 | |
| 6G0858 | 93 BRACKET AS | 2 | |
| 1F0750 | 93A NUT-WELD (3/8-16-THD) | 1 | |
| 5P7467 | 94 CLIP (TAB) | 6 |
