System And Components
121-3227 TURBOCHARGER GPS/N 5HK12000-99999
Group No: 121-3227
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1142578 | 1 ELBOW | 1 | |
| 1411710 | 2 GASKET | 1 | |
| 6I0839 | 3 BOLT (M8X1.25X70-MM) | 2 | |
| 1273361 | 4 BOLT (M8X1.25X95-MM) | 2 | |
| 1004458 | 5 BOLT (M8X1.25X14-MM) | 1 | |
| 0643058 | 6 CLAMP-HOSE | 2 | |
| 1142588 | 7 WASHER | 1 | |
| 1142580 | 8 GASKET | 1 | |
| 1313701 | 9 HOSE | 1 | |
| 1004454 | 10 NUT (M8X1.25-THD) | 4 | |
| 1142583 | 11 STUD (M8X1.25X37-MM) | 4 | |
| 1213226 | 12 TURBOCHARGER GP | 1 | |
| 1142584 | 13 TUBE | 1 | |
| 1213414 | 14 GASKET | 1 | |
| 6I0217 | 15 BOLT (M8X1.25X20-MM) | 2 | |
| 1434534 | 16 HOSE | 1 | |
| 5D1026 | 17 CLAMP-BAND | 2 | |
| 1142590 | 18 CONNECTION | 1 | |
| 1142586 | 19 TUBE | 1 | |
| 6I0220 | 20 GASKET | 1 | |
| 6I0572 | 21 BOLT (M8X1.25X20-MM) | 2 | |
| 1232927 | 22 TUBE AS | 1 | |
| 1029990 | 23 UNION | 1 |
