System And Components
150-9127 TURBOCHARGER GPS/N 5HK12000-99999; 9RM1-UP
Group No: 150-9127
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0220 | 2 GASKET | 1 | |
| 6I0303 | 3 BOLT (M10X1.5X30-MM) | 4 | |
| 6I0530 | 4 BOLT | 1 | |
| 6I0563 | 5 NUT (M10X1.5-THD) | 4 | |
| 6I0572 | 6 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0839 | 7 BOLT (M8X1.25X70-MM) | 2 | |
| 6I4003 | 8 BOLT | 1 | |
| 7W2569 | 9 GASKET-INDUCTION | 1 | |
| 7W2570 | 10 GASKET | 1 | |
| 7W2571 | 11 GASKET-INDUCTION | 1 | |
| 0358218 | 12 GASKET | 2 | |
| 1004454 | 13 NUT (M8X1.25-THD) | 4 | |
| 5D1026 | 14 CLAMP-BAND | 2 | |
| 1029990 | 15 UNION | 1 | |
| 0643058 | 16 CLAMP-HOSE | 2 | |
| 1142380 | 17 STUD | 4 | |
| 1142409 | 18 MANIFOLD-INLET | 1 | |
| 1142578 | 19 ELBOW | 1 | |
| 1142580 | 20 GASKET | 1 | |
| 1142583 | 21 STUD (M8X1.25X37-MM) | 4 | |
| 1142584 | 22 TUBE | 1 | |
| 1142586 | 23 TUBE | 1 | |
| 1142588 | 24 WASHER | 1 | |
| 1142590 | 25 CONNECTION | 1 | |
| 1213208 | 26 MANIFOLD-EXHAUST | 1 | |
| 1213226 | 27 TURBOCHARGER GP | 1 | |
| 1213414 | 28 GASKET | 1 | |
| 1232927 | 29 TUBE AS | 1 | |
| 1273361 | 30 BOLT (M8X1.25X95-MM) | 2 | |
| 1313701 | 31 HOSE | 1 | |
| 1411710 | 32 GASKET | 1 | |
| 1434534 | 33 HOSE | 1 |
