Assembly
100%

116-1243 LINES GP-FUELS/N 4MM1-802; 9SR1-357

Group No: 116-1243
Part NumberPart NameQty
09320631 GROMMET2
8T41212 WASHER-HARD (11X21X2.5-MM THK)6
8T41333 NUT (M10X1.5-THD)3
5K84514 CLIP (LOOP)1
10873035 GROMMET1
09509606 CLAMP-HOSE6
10325297 HOSE (270CM)
9M84068 CLIP (LOOP)3
11173879 TUBE2
4H249410 SLEEVE-FITTING2
7Y816711 GROMMET (50-MM ID)1
067700112 NUT-SPECIAL2
101392513 SEPARATOR GP-WATER1
033784914 PLUG2
032810015 WASHER (0.531X0.718X0.064-IN THK)2
8T413616 BOLT (M10X1.5X25-MM)2
8T413717 BOLT (M10X1.5X20-MM)1
111738818 PIPE-FUEL1
111738919 PIPE1
7K118120 STRAP-CABLE1
103252921 HOSE (320CM)
103252922 HOSE (110CM)
