System And Components
125-0094 PANEL GP-CIRCUIT BREAKERS/N 4MM395-484
Group No: 125-0094
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V5645 | 1 SCREW-MACHINE (10-32X0.87-IN) | 2 | |
| 8T0328 | 2 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 9S0174 | 3 CIRCUIT BREAKER AS (60-AMPERE) | 1 | |
| 6V8365 | SCREW-MACHINE (1/4-28X0.5-IN) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 7Y5492 | 4 COVER | 1 | |
| 8T6411 | 5 SCREW-MACHINE (M6X1X12-MM) | 16 | |
| 9X8256 | 6 WASHER (6.6X12X2-MM THK) | 16 | |
| 7N0718 | 7 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 8H8648 | 8 PLATE-INSTRUCTION (DISCONNECT SWITCH) | 1 | |
| 4I5441 | 9 BRACKET AS | 1 | |
| 3T0049 | CLIP | 4 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 10 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 8T4191 | 10 BOLT (M10X1.5X16-MM) | 7 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 4I5444 | 12 COVER | 1 | |
| 7Y5490 | 13 RELAY (24-VOLT) | 5 | |
| 7Y5493 | 14 TOOL (FUSE PULLER) | 1 | |
| 9W1442 | 15 FUSE (10-AMPERE) | 15 | |
| 9W1441 | 16 FUSE (15-AMPERE) | 4 | |
| 9W1446 | 17 FUSE (20-AMPERE) | 2 | |
| 7W1251 | 18 RESISTOR | 1 | |
| 3T0376 | 19 SWITCH AS-MAGNETIC (MAIN RELAY) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 6V8378 | NUT (10-32-THD) | 2 | |
| 7Y3937 | 20 WIRE AS | 1 | |
| 5C2890 | 21 NUT (M6X1-THD) | 2 | |
| 1132375 | 22 SWITCH AS-MAGNETIC (START RELAY) | 1 | |
| 4I5448 | 23 WIRE AS | 2 | |
| 4I5447 | 24 WIRE AS | 1 | |
| 7Y5499 | 25 BLOCK AS-TERMINAL | 1 | |
| 1221846 | 26 WIRE AS | 1 | |
| 6V5210 | 27 SCREW-MACHINE (M4X0.7X10-MM) | 4 | |
| 5P7848 | 28 NUT (M4X0.7-THD) | 2 | |
| 6V9502 | 29 LOCKWASHER | 2 | |
| 0967650 | 30 GROMMET | 1 | |
| 8M2770 | 31 CLIP (LOOP) | 1 | |
| 3S2093 | 32 STRAP-CABLE | 2 | |
| 1S0994 | 33 CLIP (LOOP) | 1 | |
| 1250148 | 34 HARNESS AS | 1 | |
| 9G2264 | 35 CLIP-CONNECTOR | 2 | |
| 9G3658 | 36 CLIP | 1 | |
| 1211022 | 37 DIODE | 1 | |
| 0966166 | 38 WASHER-HARD (4.5X9X1-MM THK) | 2 |
