System And Components
4I-3305 CONSOLE GP-OPERATORS/N 4MM1-UP; 9SR1-UP
Group No: 4I-3305
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1178127 | 1 CONSOLE GP-OPERATOR (LH)(LH) | 1 | |
| 1178126 | 2 CONSOLE GP-OPERATOR (RH)(RH) | 1 | |
| 8T4137 | 3 BOLT (M10X1.5X20-MM) | 12 | |
| 8T4121 | 4 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8C3111 | 5 ROD END | 2 | |
| 5C2890 | 6 NUT (M6X1-THD) | 2 | |
| 3W8437 | 7 ROD | 1 | |
| 9X8256 | 8 WASHER (6.6X12X2-MM THK) | 7 | |
| 0990492 | 9 LOCKNUT (M6X1-THD) | 2 | |
| 8T4971 | 10 BOLT (M6X1X30-MM) | 2 |
