System And Components
4I-3306 CONSOLE GP-OPERATORS/N 4MM1-UP; 9SR1-UP
Group No: 4I-3306
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y3173 | 1 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 19 | |
| 7Y3093 | 2 PANEL | 1 | |
| 1007709 | 3 COVER | 1 | |
| 7Y3268 | 4 COVER | 1 | |
| 4I1282 | 5 GRIP | 1 | |
| 7Y7394 | 6 SCREW-BUTTON HEAD (M8X1.25X25-MM) | 2 | |
| 7Y3155 | 7 COVER | 1 | |
| 4I0088 | 8 FILM-SLIDE LOCK | 1 | |
| 7Y3191 | 9 PANEL | 1 | |
| 7Y3165 | 10 COVER AS | 1 | |
| 8F1326 | 11 WASHER (4.2X9.5X0.8-MM THK) | 7 | |
| 7Y3154 | 12 COVER | 1 | |
| 9X2044 | 13 SCREW-TRUSS HEAD (M6X1X16-MM) | 8 | |
| 7Y3156 | 14 COVER-FRONT | 1 | |
| 4I1100 | 15 COVER | 1 | |
| 7Y3020 | 16 COVER | 1 | |
| 4I0087 | 17 FILM-INSTRUCTION | 1 | |
| 1144941 | 18 CONSOLE GP | 1 | |
| 1146328 | 19 FILM-INSTRUCTION | 1 | |
| 4H3521 | 20 SPRING | 1 | |
| 0964883 | 21 LOCKNUT (M10X1.5-THD) | 1 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 7Y3082 | 23 LEVER AS | 1 | |
| 7Y3273 | 24 PANEL AS | 1 | |
| 7Y3272 | 25 SPACER (10.4X16X1.5-MM THK) | 4 | |
| 7Y3036 | 26 LEVER | 1 | |
| 7Y3185 | 27 KNOB | 1 | |
| 7Y3184 | 28 KNOB | 1 | |
| 7Y3248 | 29 SCREW (M4X0.7X12-MM) | 2 | |
| 7Y3168 | 30 PLATE | 1 | |
| 6V5210 | 31 SCREW-MACHINE (M4X0.7X10-MM) | 2 | |
| 7Y3094 | 32 SUPPORT AS | 1 | |
| 8T4200 | 33 BOLT (M8X1.25X16-MM) | 4 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 7Y3095 | 35 SUPPORT AS | 1 | |
| 0963909 | 36 ADJUSTER | 2 | |
| 9X8256 | 37 WASHER (6.6X12X2-MM THK) | 2 | |
| 5C9553 | 38 BOLT (M6X1X16-MM) | 1 | |
| 5C2890 | 39 NUT (M6X1-THD) | 2 | |
| 7Y3133 | 40 ROD | 1 | |
| 8C3111 | 41 ROD END | 2 | |
| 6V9824 | 42 RING-RETAINING | 1 | |
| 4I0085 | 43 FILM-INSTRUCTION (ENG SPEED CTL) | 1 | |
| 4I0420 | 44 STRIP | 1 | |
| 7Y3271 | 45 SPACER (6.83X10.29X7-MM THK) | 4 | |
| 7Y3282 | 46 WASHER (1.6-MM THK) | 1 |
