5I-3281 CONSOLE GP-OPERATORS/N 4MM1-UP; 9SR1-UP

Group No: 5I-3281

Part Number	Part Name	Qty
7Y3184	1 KNOB	1
7Y3185	2 KNOB	1
4I0420	3 STRIP	1
7Y3248	4 SCREW (M4X0.7X12-MM)	2
7Y3155	5 COVER	1
7Y7394	6 SCREW-BUTTON HEAD (M8X1.25X25-MM)	2
7Y3154	7 COVER	1
4I0088	8 FILM-SLIDE LOCK	1
7Y3173	9 SCREW-BUTTON HEAD (M4X0.7X12-MM)	12
1028292	10 PANEL	1
1007709	11 COVER	1
5I3708	12 COVER	1
4I1282	13 GRIP	1
1105602	14 KNOB	1
1105560	15 LEVER AS	1
7Y3156	16 COVER-FRONT	1
8F1326	17 WASHER (4.2X9.5X0.8-MM THK)	8
7Y3165	18 COVER AS	1
7Y3267	19 COVER	1
7Y3268	20 COVER	1
7Y3191	21 PANEL	1
9X2044	22 SCREW-TRUSS HEAD (M6X1X16-MM)	4
7Y3168	23 PLATE	1
9X2044	24 SCREW-TRUSS HEAD (M6X1X16-MM)	3
7Y3273	25 PANEL AS	1
7Y3036	26 LEVER	1
1111122	27 BUSHING	2
1111121	28 SPRING	1
5I3316	29 LEVER AS	1
8T4224	30 WASHER-HARD (8.8X16X2-MM THK)	7
8T4189	31 BOLT (M8X1.25X20-MM)	3
5I3282	32 SUPPORT AS	1
6V8491	33 RING-RETAINING	2
7Y3080	34 SUPPORT AS	1
6V5210	35 SCREW-MACHINE (M4X0.7X10-MM)	2
4H3521	36 SPRING	1
0964883	37 LOCKNUT (M10X1.5-THD)	1
8T4121	38 WASHER-HARD (11X21X2.5-MM THK)	1
7Y3082	39 LEVER AS	1
4I0084	40 FILM-INSTRUCTION (PUMP CONTROL)	1
7Y3271	41 SPACER (6.83X10.29X7-MM THK)	4
7Y3173	42 SCREW-BUTTON HEAD (M4X0.7X12-MM)	4
7Y3282	43 WASHER (1.6-MM THK)	4
7Y3272	44 SPACER (10.4X16X1.5-MM THK)	4
0963909	45 ADJUSTER	2
8T4200	46 BOLT (M8X1.25X16-MM)	4
9X8256	47 WASHER (6.6X12X2-MM THK)	2
5C9553	48 BOLT (M6X1X16-MM)	1
8C3111	49 ROD END	2
5C2890	50 NUT (M6X1-THD)	2
7Y3133	51 ROD	1
6V9824	52 RING-RETAINING	1
1105601	53 CAP	1
9X2843	54 BOLT (M10X1.5X25-MM)	1
