System And Components
4E-1669 RECEPTACLE GP-AUXILIARY STARTS/N 9DM1-UP
Group No: 4E-1669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S2634 | 1 COVER AS | 1 | |
| 2P2975 | SEAL-O-RING | 2 | |
| 3S2093 | 2 STRAP-CABLE | 2 | |
| 4L6454 | 3 BOLT (3/8-16X1-IN) | 4 | |
| 8T4896 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8S4211 | 5 PLATE | 2 | |
| 9C8285 | 6 BRACKET | 1 | |
| 9M8406 | 7 CLIP (LOOP) | 1 | |
| 6G2256 | 8 CLAMP | 1 | |
| 2G8767 | 9 WASHER (10.5X60X3-MM THK) | 2 | |
| 6G2263 | 10 SPACER (10.5X19X28.5-MM THK) | 1 | |
| 8T2501 | 11 BOLT (3/8-16X2-IN) | 1 | |
| 4E4741 | 12 GUARD | 1 | |
| 9X5630 | 13 RECEPTACLE AS | 1 | |
| 1S7251 | 14 TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0747 | 15 CABLE (00-GA, BLACK)(00 GA 58 CM) | ||
| 5P0761 | 16 CABLE (00-GA, RED)(00 GA 170 CM) | ||
| 6V2722 | 17 TUBE-HEAT SHRINK (25.4-MM DIA) | ||
| 9B7237 | 18 BOLT (3/8-16X1.25-IN) | 1 | |
| 6V8801 | 19 NUT (3/8-16-THD) | 1 |
