121-3059 HOOD & GUARD GPS/N 5FN1-UP

Group No: 121-3059
Part NumberPart NameQty
8T41211 WASHER-HARD (11X21X2.5-MM THK)8
8T41362 BOLT (M10X1.5X25-MM)18
5P74833 SEAL (340CM)
8R92504 STRIP2
12364395 PANEL AS (LH)1
1236438PANEL AS (RH)1
12364356 DOOR AS1
1236434DOOR AS1
8R9245HINGE1
9C3293PIN1
17824917 PIN AS2
9M5733RIVET-POP2
7X77298 WASHER (11X25X3-MM THK)12
8R92529 STRIP2
8R923010 DOOR AS1
8R9239DOOR AS1
8R9237HINGE1
8R9238HINGE1
8T3612NUT-WELD (M8X1.25-THD)4
9C3861PIN1
8R925111 PLATE2
8T412112 WASHER-HARD (11X21X2.5-MM THK)20
8T413613 BOLT (M10X1.5X25-MM)8
7I301714 HOOD AS1
8T3490NUT-WELD (M10X1.5-THD)2
8T413315 NUT (M10X1.5-THD)12
2R149816 GROMMET3
8R926017 SUPPORT AS1
4L645418 BOLT (3/8-16X1-IN)2
5B0486SPACER (10.5X16X6.5-MM THK)(6.5MM THK)2
6V8801NUT (3/8-16-THD)2
5P107619 WASHER-HARD (13.5X30X4-MM THK)2
6V8188NUT (1/2-13-THD)2
9V0344PIN (LATCH STRIKER)2
8R922020 ROD1
4E239921 ROD1
9V035022 BRACKET AS (RH)1
9V0353BRACKET AS (LH)1
8T412123 WASHER-HARD (11X21X2.5-MM THK)2
8T413624 BOLT (M10X1.5X25-MM)4
9V035425 LATCH2
3B206226 PIN2
3B461527 PIN-COTTER6
7X060828 WASHER-HARD (10.2X16X2-MM THK)4
6V8183NUT-FULL (3/8-24-THD)2
1B0676PIN2
1M1341END-YOKE ROD2
7X138729 WASHER (10.26X22.22X1.9-MM THK)4
2P934730 SPRING2
8P854031 GROMMET2
0L117032 HANDLE-LEVER2
8T422233 WASHER-PLATED (11X32X2.5-MM THK)2
8T418934 BOLT (M8X1.25X20-MM)8
5P4116WASHER-HARD (8.8X20.5X2-MM THK)8
5C7261NUT (M8X1.25-THD)8
123644035 ANGLE2
8R924936 ANGLE2
9X204337 SCREW-TRUSS HEAD (M6X1X14-MM)8
8T4205WASHER-HARD (7.2X14.5X2-MM THK)8
6V7743LOCKNUT (M6X1-THD)8
9X229938 LATCH AS2
9V595439 ROD AS2
1A4784WASHER (10.3X22.2X2.5-MM THK)(2.5MM THK)2
4M747040 GROMMET2
3B461141 PIN-COTTER2
123103042 SUPPORT AS (RH)1
4V7412BOSS (3/8-16-THD)1
1231028SUPPORT AS1
8R922143 ANGLE (LH)2
8R9222ANGLE (RH)2
9C458244 ANGLE1
9C3391ANGLE1
6V880145 NUT (3/8-16-THD)6
4H255846 GROMMET2
5P107547 WASHER-HARD (10.2X22.5X3-MM THK)6
