System And Components
132-6656 DRIVE GP-FANS/N 7BR1-99999
Group No: 132-6656
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N5270 | 1 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 4N0955 | DOWEL (1/4X1.375IN) | 1 | |
| 5B5821 | DOWEL (3/8X1IN) | 1 | |
| 8T4835 | 2 BOLT (1/2-13X2-IN) | 3 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 5S9062 | 4 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 5S2106 | 5 SEAL-LIP TYPE | 1 | |
| 8H9789 | 6 BALL BEARING | 1 | |
| 1326653 | 7 SPACER | 1 | |
| 9F4446 | 8 SEAL-O-RING | 1 | |
| 1326633 | 9 BEARING | 1 | |
| 0T0573 | 10 BOLT (3/8-16X2.75-IN) | 6 | |
| 1D4717 | 11 NUT (3/8-16-THD) | 6 | |
| 1326655 | 12 HUB-FAN PULLEY | 1 | |
| 7N2900 | 13 RETAINER | 1 | |
| 5P7979 | 14 BOLT-LOCKING (5/16-24X2.25-IN)(5/16X2.25IN) | 2 | |
| 1N4502 | 15 PULLEY-FAN DRIVE | 1 | |
| 4P8087 | 16 V-BELT SET (INCLUDES 3-BELTS)(CONSISTS OF 3) | 1 | |
| 7N3629 | 17 ADAPTER-FAN | 1 | |
| 3B8485 | 18 ELBOW | 1 | |
| 6N4111 | 19 BRACKET AS | 1 | |
| 2M0306 | BLOCK-TUBE | 1 | |
| 6L3616 | 20 CONNECTOR | 1 | |
| 9S7720 | 21 ELBOW-FLARED | 1 | |
| 9B7237 | 22 BOLT (3/8-16X1.25-IN) | 2 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7D1728 | 24 CLIP (1/4IN DIA) | 1 |
