System And Components
9Y-8722 DRIVE GP-FANS/N 7BR1-99999
Group No: 9Y-8722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8485 | 1 ELBOW | 1 | |
| 6N4111 | 2 BRACKET AS | 1 | |
| 0S1588 | 3 BOLT (3/8-16X1.25-IN) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1A1460 | 4 BOLT (1/2-13X2-IN) | 3 | |
| 2M0849 | WASHER-HARD (13.5X25.5X5-MM THK) | 3 | |
| 7D1728 | 5 CLIP (1/4IN DIA) | 1 | |
| 5P1198 | 6 TUBE (49CM) | ||
| 4B8756 | 7 NUT-FLARED (7/16-24-THD) | 2 | |
| 6L3616 | 8 CONNECTOR | 1 | |
| 6N5270 | 9 BRACKET AS-FAN | 1 | |
| 1P9946 | SHAFT-FAN | 1 | |
| 4N0955 | 10 DOWEL (1/4X1.375IN) | 1 | |
| 5B5821 | 11 DOWEL (3/8X1IN) | 1 | |
| 1S9209 | 12 SHAFT-TIGHTENER | 1 | |
| 9S7720 | 13 ELBOW-FLARED | 1 | |
| 7C2500 | 14 V-BELT SET | 1 | |
| 4N8182 | 15 PULLEY-FAN DRIVE | 1 | |
| 7N3629 | 16 ADAPTER-FAN | 1 | |
| 5P7979 | 17 BOLT-LOCKING (5/16-24X2.25-IN)(5/16X2.25IN) | 2 | |
| 7N2900 | RETAINER | 1 | |
| 3L1425 | 18 BALL BEARING | 1 | |
| 0T0573 | 19 BOLT (3/8-16X2.75-IN) | 6 | |
| 1D4717 | NUT (3/8-16-THD) | 6 | |
| 9F4446 | 20 SEAL-O-RING | 1 | |
| 2P1757 | 21 HUB-FAN PULLEY | 1 | |
| 2P2243 | 22 SPACER (1.438X1.75X1.722-IN THK) | 1 | |
| 8H9789 | 23 BALL BEARING | 1 | |
| 5S2106 | 24 SEAL-LIP TYPE | 1 | |
| 5S9062 | 25 SPACER (35.032X50.8X15.88-MM THK) | 1 |
