273-4183 HOUSING GP-FLYWHEELS/N 99C9805-99999; 48W44859-99999

Group No: 273-4183
Part NumberPart NameQty
10561381 HOUSING AS-FLYWHEEL1
1056140HOUSING-FLYWHEEL1
1W31361A BAFFLE1
0S16192 BOLT (3/8-16X3-IN)4
16172933 GASKET-CYLINDER1
9M42254 BOLT (3/8 NCX4 3/8)2
1A59645 BOLT (3/8-16X4.5-IN)2
2P27726 COVER2
4N09337 GASKET2
1A20298 BOLT (3/8-16X1.125-IN)2
5M28949 WASHER-HARD (10.2X18.5X2.5-MM THK)16
8T676510 PLUG-PIPE (1/4-18-THD)3
5P824511 WASHER-HARD (13.5X25.5X3-MM THK)8
0S158812 BOLT (3/8-16X1.25-IN)(MARKED Y)6
3S003613 PLUG-CORE2
3D287114 STUD-TAPERLOCK (3/8-16X1.5-IN)2
8T676115 PLUG-PIPE (1-11-1/2 NPT THD)1
0L135216 BOLT (3/8-16X3.25-IN)1
8M912417 WASHER (10X22.5X8-MM THK)1
2H648818 BOLT (1/2-13X5-IN)(MARKED X)8
5F030419 PLUG (FLYWHEEL HOUSING OIL DRAIN)1
2A116220 GASKET1
4C961221 SEALANT-SILICONE
